System And Components
329-3308 LINES GP-ACCUMULATORS/N 8801-UP
Group No: 329-3308
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X2538 | 1 ELBOW | 1 | |
| 9X6772 | 2 STRAP-CABLE | 1 | |
| 1164491 | 3 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1445194 | 4 HOSE AS | 1 | |
| 1475608 | 5 HOSE AS | 1 | |
| 1488447 | 6 TEE AS-SWIVEL | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 7X0872 | TEE-SWIVEL | 1 | |
| 1604128 | 7 VALVE GP-PRESSURE REDUCING (IMPLEMENT PILOT OIL) | 1 | |
| 1854026 | 8 VALVE GP-CHECK (PILOT ACCUMULATOR) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1940800 | 9 HOSE AS | 1 | |
| 2006345 | 10 SADDLE-MOUNTING (DUAL SWIVEL) | 2 | |
| 2042281 | 11 STRAP-CABLE | 6 | |
| 2048000 | 12 MOUNTING-CABLE TIE | 1 | |
| 2071810 | 13 VALVE GP-CHECK (PILOT) | 1 | |
| 2416215 | 14 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8076 | ELBOW | 1 | |
| 2452975 | 15 ACCUMULATOR GP-HYDRAULIC (CHARGED) | 1 | |
| 2609187 | 16 CONNECTOR AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T9358 | CONNECTOR | 1 | |
| 2617957 | 17 ADAPTER-CROSS | 1 | |
| 2695360 | 18 HOSE AS | 1 | |
| 2956259 | 19 FILTER GP-OIL | 1 | |
| 3019285 | 20 HOSE AS | 1 | |
| 3447389 | 21 SENSOR AS-PRESSURE (PILOT ACCUMULATOR) | 1 | |
| 3447391 | 22 SENSOR-PRESSURE (CONTROL VALVE) | 2 | |
| 3463725 | 23 HOSE AS | 1 | |
| 3463733 | 24 HOSE AS | 1 | |
| 3463734 | 25 HOSE AS | 1 | |
| 3463735 | 26 HOSE AS | 1 | |
| 3463738 | 27 TUBE AS | 1 | |
| 3463739 | 28 BRACKET | 1 | |
| 3463764 | 29 PLATE | 1 | |
| 3463765 | 30 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3507757 | 31 HOSE AS | 1 | |
| 3507788 | 32 PLATE AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 3614042 | 33 HOSE AS | 1 | |
| 3614043 | 34 HOSE AS | 1 | |
| 3614044 | 35 HOSE AS | 1 | |
| 3614045 | 36 HOSE AS | 1 | |
| 1013470 | 37 CLAMP-HALF | 2 | |
| 1488324 | 38 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9874 | CONNECTOR | 1 | |
| 1488341 | 39 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488376 | 40 ELBOW AS | 1 | |
| 6V8983 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1488382 | 41 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8T0404 | ELBOW | 1 | |
| 1488414 | 42 REDUCER AS | 1 | |
| 6V8943 | REDUCER | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488416 | 43 REDUCER AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8939 | REDUCER-O-RING | 1 | |
| 1488418 | 44 REDUCER AS | 2 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8942 | REDUCER-O-RING | 1 | |
| 1488427 | 45 TEE AS | 1 | |
| 6V8398 | SEAL-O-RING | 3 | |
| 8T6895 | TEE-UNION | 1 | |
| 1488442 | 46 TEE AS | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8T1685 | TEE | 1 | |
| 1504043 | 47 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9873 | CONNECTOR | 1 | |
| 1504048 | 48 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8722 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1697404 | 49 ELBOW AS | 1 | |
| 6V8982 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 2226869 | 50 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 9X2614 | CONNECTOR | 1 | |
| 2877308 | 51 TEE | 1 | |
| 2P1293 | 52 LOCKNUT (1-3/16-12-THD) | 1 | |
| 3D2824 | 53 SEAL-O-RING | 1 | |
| 3J1907 | 54 SEAL-O-RING | 3 | |
| 6V8398 | 55 SEAL-O-RING | 2 | |
| 9X6581 | 56 NUT-O-RING SEAL (1-14-THD) | 1 | |
| 9X6580 | 57 NUT (1-3/16-12-THD) | 2 | |
| 6V9168 | 58 NUT (11/16-16-THD) | 2 | |
| 6V9169 | 59 NUT (13/16-16-THD) | 1 | |
| 6V9170 | 60 NUT-BULKHEAD (1-14-THD) | 1 | |
| 6V9746 | 61 SEAL-O-RING | 4 | |
| 7J9108 | 62 SEAL-O-RING | 3 | |
| 7X0531 | 63 WASHER-HARD (31X52.5X6-MM THK) | 1 | |
| 8T4121 | 64 WASHER-HARD (11X21X2.5-MM THK) | 13 | |
| 8T4136 | 65 BOLT (M10X1.5X25-MM) | 5 | |
| 8T4137 | 66 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4139 | 67 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4167 | 68 WASHER-HARD (26X44X4-MM THK) | 1 | |
| 8T4195 | 69 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 70 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4224 | 71 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4956 | 72 BOLT (M12X1.75X35-MM) | 2 | |
| 8T6869 | 73 BOLT (M8X1.25X60-MM) | 2 | |
| 9K1120 | 74 GROMMET | 1 | |
| 9R1004 | 75 CLIP (TAB) | 2 | |
| 9R1005 | 76 CLIP (SLOT) | 2 | |
| 2062727 | 77 GUARD-HOSE (63-CM) |
