System And Components
367-4374 TANK GP-COOLANTS/N L8S1-UP
Group No: 367-4374
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6L8617 | 1 CAP-PRESSURE (7-PSI)(COOLANT TANK) | 1 | |
| 8X7521 | 2 PLATE AS | 1 | |
| 9Y9236 | 3 GAUGE-SIGHT (COOLANT LEVEL) | 1 | |
| 0532313 | 4 CONNECTOR | 1 | |
| 3650581 | 5 CONNECTOR AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1808424 | SEAL-O-RING | 1 | |
| 3679850 | 6 TANK GP-COOLANT | 1 | |
| 3793048 | 7 HOSE AS | 3 | |
| 3920810 | 8 TEE AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 1180911 | TEE-O-RING PORT | 1 | |
| 3985640 | 9 ELBOW AS | 1 | |
| 6D7128 | SEAL-O-RING | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 3985641 | 10 CONNECTOR AS | 3 | |
| 6D7128 | SEAL-O-RING | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 4362826 | 11 TUBE AS | 1 | |
| 4362828 | 12 TUBE AS | 1 | |
| 4384805 | 13 HOSE AS | 1 | |
| 4434954 | 14 VALVE AS | 1 | |
| 7N7688 | FERRULE | 1 | |
| 9M5590 | BALL | 1 | |
| 4500116 | 15 BRACKET AS | 1 | |
| 4500120 | 16 HOSE AS | 1 | |
| 1214345 | 17 SEAL-O-RING | 4 | |
| 2022762 | 18 CLIP (LOOP) | 7 | |
| 2492757 | 19 CLIP | 1 | |
| 2843502 | 20 CLAMP-BAND | 2 | |
| 3180820 | 21 GROMMET | 1 | |
| 3328555 | 22 ADAPTER AS | 1 | |
| 8M0506 | ADAPTER-O-RING | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 4D7388 | 23 CLIP | 3 | |
| 5P9299 | 24 CLIP (LOOP) | 5 | |
| 6V5064 | 25 SEAL-O-RING | 1 | |
| 6V6609 | 26 SEAL-O-RING | 1 | |
| 6V7383 | 27 CLIP | 1 | |
| 7X7729 | 28 WASHER (11X25X3-MM THK) | 7 | |
| 8T1889 | 29 CLIP (SLOT) | 1 | |
| 8T1890 | 30 CLIP (TAB) | 1 | |
| 8T4121 | 31 WASHER-HARD (11X21X2.5-MM THK) | 11 | |
| 8T4136 | 32 BOLT (M10X1.5X25-MM) | 7 | |
| 8T4137 | 33 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4195 | 34 BOLT (M10X1.5X30-MM) | 5 | |
| 8T6466 | 35 BOLT (M10X1.5X60-MM) | 2 | |
| 9W1991 | 36 SPACER (10.7X17.1X40-MM THK) | 2 | |
| 3496239 | 37 HOSE (232-CM) | ||
| 7Y1976 | 38 HOSE-WATER (220-CM) |
