System And Components
473-5443 LINES GP-ENGINE OILAN ATTACHMENT
Group No: 473-5443
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4712751 | 1 SPRING | 1 | |
| 1W2447 | 2 ADAPTER-OUTLET | 1 | |
| 2W1053 | 3 PLUG | 1 | |
| 6B9202 | 4 SPRING | 2 | |
| 7N7697 | 5 PLUNGER AS (SEQUENCE VALVE) | 2 | |
| 7M1808 | DOWEL | 1 | |
| 8N2929 | 6 COVER | 2 | |
| 1244273 | 7 VALVE-BYPASS | 1 | |
| 1363296 | 8 FLANGE | 1 | |
| 1467359 | 9 TUBE | 1 | |
| 1506611 | 10 BONNET | 1 | |
| 1506612 | 11 ELBOW-OUTLET | 1 | |
| 1539963 | 12 RING | 2 | |
| 2377623 | 13 SEAL-O-RING | 2 | |
| 2445867 | 14 ELBOW | 1 | |
| 2456848 | 15 CLAMP AS | 4 | |
| 2474806 | 16 ELBOW | 1 | |
| 2859361 | 17 BONNET | 1 | |
| 2869966 | 18 BRACKET | 1 | |
| 3654215 | 19 ADAPTER | 1 | |
| 1653931 | 20 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1585 | 21 BOLT (1/2-13X1.5-IN) | 2 | |
| 0S1588 | 22 BOLT (3/8-16X1.25-IN) | 8 | |
| 1653929 | 23 BOLT (3/8-16X1.5-IN) | 2 | |
| 0T0065 | 24 BOLT (3/8-16X3.5-IN) | 8 | |
| 1A2029 | 25 BOLT (3/8-16X1.125-IN) | 8 | |
| 2287097 | 26 SEAL-O-RING | 1 | |
| 3P0655 | 27 SEAL-O-RING | 1 | |
| 3S1546 | 28 NUT-FULL (7/16-14-THD) | 4 | |
| 4F8965 | 29 BOLT (7/16-14X1.125-IN) | 4 | |
| 5M2894 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 5P4892 | 31 SEAL-O-RING | 1 | |
| 5P8244 | 32 WASHER-HARD (12X22.5X2.5-MM THK) | 8 | |
| 6B0933 | 33 SPACER (10.31X19.05X6.35-MM THK) | 4 | |
| 6J2244 | 34 SEAL-O-RING | 1 | |
| 6V3908 | 35 SEAL-O-RING | 1 | |
| 6V4368 | 36 SEAL-O-RING | 2 | |
| 6V4589 | 37 SEAL-O-RING | 2 | |
| 6V6609 | 38 SEAL-O-RING | 2 | |
| 8B9725 | 39 BOSS | 5 | |
| 8C3107 | 40 SEAL-O-RING | 1 | |
| 8T6765 | 41 PLUG-PIPE (1/4-18-THD) | 2 | |
| 9S1366 | 42 BOLT (1/2-13X2.5-IN) | 2 | |
| 9S4185 | 43 PLUG (3/4-16-THD) | 2 | |
| 9S4190 | 44 PLUG-O-RING (7/8-14-THD) | 2 | |
| 2B0947 | 45 BOLT (1/2-13X2.25-IN) | 1 |
