System And Components
421-1596 BASE GP-FUEL FILTERS/N DSJ1-UP
Group No: 421-1596
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0436 | 1 GASKET (FUEL PRIMING PUMP) | 1 | |
| 2S3992 | 2 SPRING | 1 | |
| 6N6248 | 3 PLATE | 1 | |
| 6N6251 | 4 LEVER | 1 | |
| 7E5346 | 5 VALVE AS | 1 | |
| 1375541 | 6 PUMP GP-FUEL PRIMING | 1 | |
| 2293218 | VALVE AS | 2 | |
| 1396873 | 7 VALVE GP-FUEL BYPASS (FILTER) | 1 | |
| 2847495 | 8 VALVE | 1 | |
| 3016388 | 9 JUNCTION BLOCK | 1 | |
| 4211580 | 10 SPACER (8.2X12.7X22.8-MM THK) | 3 | |
| 4221062 | 11 BASE AS-FUEL FILTER | 1 | |
| 8N3653 | STUD-TAPERLOCK | 2 | |
| 1367227 | 12 SEAL-O-RING | 1 | |
| 1B2790 | 13 BOLT (5/16-18X1.375-IN) | 1 | |
| 1B9575 | 14 BOLT (5/16-18X1.56-IN) | 3 | |
| 1R0755 | 15 FILTER-FUEL (ADVANCED EFFICIENCY) | 2 | |
| 2B2694 | 16 BOLT (5/16-18X2-IN) | 2 | |
| 2D6642 | 17 BALL | 1 | |
| 2K8467 | 18 PIN-SPRING | 1 | |
| 3006714 | 19 MOUNT | 6 | |
| 3072673 | 20 PLUG AS | 3 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196234 | 21 PLUG AS | 1 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3H3385 | 22 SEAL-O-RING | 1 | |
| 4H1641 | 23 PIN-SPRING | 1 | |
| 5P0537 | 24 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 6L3428 | 25 SCREW-MACHINE | 2 | |
| 6V5048 | 26 SEAL-O-RING | 1 | |
| 6V6228 | 27 SEAL-O-RING | 1 | |
| 7B2742 | 28 BOLT (1/4-20X1.25-IN) | 1 | |
| 9M1974 | 29 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9N0869 | 30 WASHER-HARD (8.8X25.5X2-MM THK) | 6 | |
| 9S4182 | 31 PLUG (7/16-20-THD) | 1 | |
| 9X7385 | 32 SEAL-O-RING | 1 |
