System And Components
474-9932 MANIFOLD GP-EXHAUSTAN ATTACHMENT
Group No: 474-9932
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3571752 | 1 GASKET-TURBOCHARGER | 2 | |
| 4289129 | 2 GASKET (SPIRAL WOUND) | 12 | |
| 4289130 | 3 GASKET (SPIRAL WOUND) | 16 | |
| 4749917 | 4 BELLOWS AS | 2 | |
| 4749933 | 5 MANIFOLD GP-EXHAUST | 1 | |
| 4P7680 | 6 SPACER (10.5X22.5X15-MM THK) | 8 | |
| 1003145 | 7 MANIFOLD-EXHAUST (FRONT, RH) | 1 | |
| 1003146 | 8 MANIFOLD-EXHAUST (INTERMEDIATE, RH) | 2 | |
| 1003148 | 9 MANIFOLD-EXHAUST (INTERMEDIATE, LH) | 3 | |
| 1278269 | 10 SEAL-EXHAUST | 2 | |
| 2224701 | 11 BELLOWS AS | 5 | |
| 3536113 | 12 SPACER (11X20X20-MM THK) | 4 | |
| 3788994 | 13 CLAMP-BAND | 9 | |
| 4404377 | 14 BELLOWS AS | 3 | |
| 4435940 | 15 BELLOWS AS | 2 | |
| 4461290 | 16 CLAMP-V BAND | 8 | |
| 4497299 | 17 BELLOWS AS | 2 | |
| 4580828 | 18 ELBOW | 1 | |
| 4533607 | 19 GASKET-EXHAUST | 1 | |
| 4616611 | 20 ELBOW-EXHAUST | 3 | |
| 4749918 | 21 SLEEVE-EXHAUST | 2 | |
| 4749919 | 22 MANIFOLD GP-EXHAUST | 1 | |
| 4749921 | 23 BYPASS GP-EXHAUST | 1 | |
| 4749928 | 24 MANIFOLD-EXHAUST | 1 | |
| 4749930 | 25 MANIFOLD-EXHAUST | 1 | |
| 4749934 | 26 BOLT (3/8-16X6.25-IN) | 2 | |
| 4811091 | 27 BOLT (3/8-16X4-IN) | 4 | |
| 4823753 | 28 SPACER (10.5X20.5X6.2-MM THK) | 16 | |
| 4915545 | 29 ADAPTER | 2 | |
| 4915547 | 30 MANIFOLD-EXHAUST | 1 | |
| 4915548 | 31 MANIFOLD-EXHAUST | 1 | |
| 4915553 | 32 SLEEVE AS | 1 | |
| 2194458 | PIN-DOWEL | 1 | |
| 5664151 | 33 VALVE & MOUNTING GP (NRS) | 1 | |
| 1108314 | 34 WASHER (10.3X18.3X2.66-MM THK) | 104 | |
| 2N2766 | 35 LOCKNUT (3/8-16-THD) | 68 | |
| 3008579 | 36 BOLT (3/8-16X2.5-IN) | 4 | |
| 4377470 | 37 BOLT (3/8-16X5-IN) | 2 | |
| 5M2894 | 38 WASHER-HARD (10.2X18.5X2.5-MM THK) | 48 | |
| 5P3345 | 39 BOLT (3/8-16X3-IN) | 4 | |
| 5P7128 | 40 BOLT-HIGH TEMPERATURE (3/8-16X2-IN) | 8 | |
| 7L6443 | 41 BOLT-HIGH TEMPERATURE (3/8-16X2.25-IN) | 48 | |
| 9L7373 | 42 BOLT-HIGH TEMPERATURE (3/8-16X2-IN) | 48 | |
| 5530161 | 43 SHIELD AS-MANIFOLD | 1 |
