System And Components
560-1407 SENSOR & MOUNTING GPAN ATTACHMENT
Group No: 560-1407
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0966166 | 1 WASHER-HARD (4.5X9X1-MM THK) | 4 | |
| 0S1594 | 2 BOLT (3/8-16X1-IN) | 4 | |
| 3068526 | 3 GROMMET | 4 | |
| 4L6454 | 4 BOLT (3/8-16X1-IN) | 4 | |
| 5504761 | 5 SENSOR GP-CURRENT (LH) | 1 | |
| 5504761 | 5A SENSOR GP-CURRENT (RH) | 1 | |
| 5559030 | 6 BRACKET AS | 2 | |
| 5570261 | 7 HARNESS AS-SENSOR (LH) | 1 | |
| 5570261 | 7A HARNESS AS-SENSOR (RH) | 1 | |
| 6V8801 | 8 NUT (3/8-16-THD) | 4 | |
| 8T1889 | 9 CLIP (SLOT) | 4 | |
| 8T1890 | 10 CLIP (TAB) | 4 | |
| 8T4896 | 11 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 9X6016 | 12 SCREW-HEX SOCKET (8-32X0.875-IN) | 4 | |
| 9X6458 | 13 WASHER-HARD (10.2X22.5X3-MM THK) | 4 |
