System And Components
463-3033 DAMPER GPS/N NAW1-UP
Group No: 463-3033
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 9 | |
| 2514889 | 2 WASHER-HARD (7.2X14.5X2-MM THK) | 5 | |
| 4633028 | 3 SHAFT | 1 | |
| 4633030 | 4 ACTUATOR | 1 | |
| 4633032 | 5 BRACKET AS | 1 | |
| 4633034 | 6 DAMPER | 1 | |
| 4633035 | 7 DAMPER | 2 | |
| 4633089 | 8 BOLT AS | 6 | |
| 4633090 | 9 BEARING | 3 | |
| 4633094 | 10 FLANGE | 2 | |
| 4633095 | 11 BRACKET | 1 | |
| 3401530 | 12 BOLT-FLANGE HEAD (M6X1X18-MM) | 9 | |
| 3445673 | 13 NUT (M6X1-THD) | 9 | |
| 5P4115 | 14 WASHER-HARD (7.2X19X2-MM THK) | 25 | |
| 6V0292 | 15 PLUG | 1 | |
| 8T6974 | 16 BOLT (M6X1X80-MM) | 3 | |
| 9X8256 | 17 WASHER (6.6X12X2-MM THK) | 3 | |
| 6V6604 | 18 SEAL (0.06-M EACH) | 1 | |
| 5P5930 | 19 SEAL (0.06-M EACH) | 1 | |
| 3987367 | 20 SEAL (5.3-DM) | ||
| 3987367 | 20A SEAL (5.4-DM EACH) |
