Assembly
100%

434-7607 GUARD GP-BELTS/N K3B692-UP; X3F1-UP

Group No: 434-7607
Part NumberPart NameQty
8T42241 WASHER-HARD (8.8X16X2-MM THK)1
10197622 MOUNT9
43476013 GUARD AS1
8T3612NUT-WELD (M8X1.25-THD)4
43476024 GUARD AS1
8T3612NUT-WELD (M8X1.25-THD)3
43476035 GUARD AS1
43476046 BRACKET AS1
8T3612NUT-WELD (M8X1.25-THD)3
43476057 BRACKET AS1
8T3612NUT-WELD (M8X1.25-THD)2
43476068 BRACKET AS1
8T3612NUT-WELD (M8X1.25-THD)2
43476089 BRACKET AS1
8T3612NUT-WELD (M8X1.25-THD)2
2768166SPACER (12X40X7-MM THK)2
174418110 WASHER-HARD (8.5X40X3-MM THK)9
5C726111 NUT (M8X1.25-THD)1
5P256612 BOLT (1/2-13X1.5-IN)1
5P411613 WASHER-HARD (8.8X20.5X2-MM THK)7
7X081814 BOLT (M8X1.25X45-MM)2
8T420015 BOLT (M8X1.25X16-MM)7
8T422316 WASHER-HARD (13.5X25.5X3-MM THK)1
8T754717 BOLT (M8X1.25X30-MM)7
