System And Components
4N9544 TURBOCHARGER GROUP-FIELD INSTALLATION*RENGINE SERIAL NO. 49V20838-UP
Group No: 4N9544
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N9534 | 1 CARTRIDGE GP-TURBOCHARGER | 1 | |
| 7N0239 | NUT-TURBO COMPRESSOR | 1 | |
| 9N2378 | 2 WHEEL-COMPRESSOR | 1 | |
| 5S4556 | 3 INSERT | 1 | |
| 5S4546 | 4 RING-RETAINING | 1 | |
| 5P5757 | 5 SEAL-O-RING | 1 | |
| 5S4554 | 6 SEAL-O-RING | 1 | |
| 8S9223 | 7 BEARING-THRUST | 1 | |
| 5S4550 | 8 RING-THRUST | 2 | |
| 5S4557 | 9 BEARING | 2 | |
| 4M6983 | 10 RING-RETAINING | 4 | |
| 4N9540 | 11 HOUSING AS-CENTER | 1 | |
| 5S5199 | PIN-GROOVE | 2 | |
| 4N9556 | 12 SHROUD | 1 | |
| 4M6990 | 13 RING-SNAP | 1 | |
| 5S4551 | 14 SLEEVE-OIL CONTROL | 1 | |
| 4N7595 | 15 RING | 1 | |
| 8S4989 | 16 WHEEL AS | 1 | |
| 8H3710 | 17 SCREW-TAPPING | 2 | |
| 9S1180 | 18 NAMEPLATE | 1 | |
| 5S4547 | 19 SLEEVE-SPACER | 1 | |
| 5S4549 | 20 DEFLECTOR-OIL | 1 | |
| 8S9222 | 21 SLEEVE | 1 | |
| 4M8013 | 22 RING-PISTON | 2 | |
| 5S4517 | 23 CLAMP AS | 1 | |
| 7M9918 | NUT-SELF LOCKING | 1 | |
| 8S9225 | 24 HOUSING | 1 | |
| 5S4558 | 25 CLAMP AS-COMPRESSOR | 1 | |
| 7M9918 | NUT-SELF LOCKING | 1 | |
| 4N3755 | 26 COVER-COMPRESSOR | 1 | |
| 5S4545 | 27 NAMEPLATE | 1 | |
| 6N7245 | KIT-CARTRIDGE REPAIR (INCL PARTS MARKED J) | 1 |
