1W8347 AFTERCOOLER GP-WATERENGINE S/N 70V21801-UP

Group No: 1W8347
Part NumberPart NameQty
1B95751 BOLT11
9M19742 WASHER26
8N80993 COVER-AFTERCOOLER1
5M62134 PLUG1
9F89995 BOLT4
5M28946 WASHER18
1W05127 COVER-AFTERCOOLER1
7W06888 GASKET-ADAPTER2
8N81009 ADAPTER1
2S616010 WASHER-HARD1
4N900811 GASKET2
6L958912 GASKET2
5D984413 BOLT-SELF LOCKING1
4W477514 ADAPTER2
4N419315 ADAPTER2
9M700216 SEAL-O-RING2
5P720417 SEAL-O-RING2
1W487918 CORE AS-AFTERCOOLER1
8N809819 HOUSING-AFTERCOOLER1
5M621420 PLUG-PIPE2
2N820421 GASKET6
3M704522 PLUG1
031021923 BOLT-SELF LOCKING10
5B562024 BOLT21
2B085825 PLUG-PIPE1
1B957526 BOLT1
1D471727 NUT (FULL)4
031021928 BOLT-SELF LOCKING1
5M2894WASHER1
3J538929 PLUG (PIPE)1
5M621430 PLUG-PIPE1
1B957531 BOLT 44.45MM(1.75IN) LG1
5B5620BOLT 53.98MM(2.13IN) LG1
