System And Components
8N4780 CARTRIDGE ASSEMBLY*RPART OF 8N4774 TURBOCHARGER GROUP SHOWN ON PAGE 30
Group No: 8N4780
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P1125 | 1 LOCKNUT-TURBOCHARGER | 1 | |
| 8N4781 | 2 WHEEL-COMPRESSOR | 1 | |
| 1P1111 | 3 BEARING-THRUST | 1 | |
| 2P9607 | 4 RING-RETAINING | 4 | |
| 7N6609 | 5 RING-PISTON | 1 | |
| 1P1116 | 6 SHAFT & WHEEL AS | 1 | |
| 7N0012 | 7 SHROUD-TURBINE WHEEL | 1 | |
| 1P1114 | 8 BEARING-TURBOCHARGER | 2 | |
| 2P9635 | 9 HOUSING AS-CENTER | 1 | |
| 4M6646 | PIN-GROOVE | 2 | |
| 1P1120 | 10 RING-SEAL | 1 | |
| 4N6863 | 11 BACKPLATE AS | 1 | |
| 1P1124 | 12 RING-PISTON | 1 | |
| 1P1123 | 13 COLLAR-THRUST | 1 | |
| 1P1117 | 14 PLATE-LOCK | 2 | |
| 2A0762 | 15 BOLT | 4 | |
| 7N2434 | NAMEPLATE-CARTRIDGE | 1 | |
| 2F0808 | SCREW | 2 | |
| 2W0716 | KIT-TURBOCHARGER CARTRIDGE | 1 |
