System And Components
9T3704 HEAD GP-PUMP CONTROLS/N 76U5505-Up
Group No: 9T3704
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9T3767 | 1 VALVE GP | 1 | |
| 9T3047 | 2 COVER | 1 | |
| 9T3418 | 3 HEAD | 1 | |
| 9T3400 | 4 PISTON-ACTUATING | 1 | |
| 9T3401 | 5 FORK | 1 | |
| 9T3398 | 6 SLEEVE | 1 | |
| 9T3399 | 7 SPOOL-CONTROL | 1 | |
| 9T3413 | 8 BRACKET | 1 | |
| 9T3367 | 9 SPRING | 1 | |
| 9T3412 | 10 BUSHING | 1 | |
| 9T3411 | 11 SPRING | 1 | |
| 9T3416 | 12 GUIDE | 1 | |
| 9T3417 | 13 COLLAR | 1 | |
| 9T3420 | 14 SPRING | 1 | |
| 9T3373 | 15 COLLAR | 1 | |
| 9T3383 | 16 PLUG | 1 | |
| 9T3372 | 17 SETSCREW | 1 | |
| 9T3405 | 18 PIN | 2 | |
| 9T3374 | 19 PIN | 1 | |
| 9T3414 | 20 LEVER-CONTROL | 1 | |
| 9T3390 | 21 SETSCREW | 1 | |
| 9T3381 | 22 SPRING | 1 | |
| 9T3382 | 23 GASKET | 1 | |
| 9T3048 | 24 LOCKNUT-SEAL | 2 | |
| 9T3853 | 25 LOCKNUT | 1 | |
| 8T5447 | 26 RING-RETAINING | 6 | |
| 8T7942 | 27 DOWEL | 2 | |
| 8T7941 | 28 DOWEL | 2 | |
| 6V3922 | 29 SEAL-O-RING | 1 | |
| 9T3881 | 30 BALL BEARING AS | 1 | |
| 9T3939 | 31 BEARING-NEEDLE | 1 | |
| 8T8443 | 32 BOLT-SOCKET HEAD | 4 | |
| 8T3957 | 33 BOLT-HEX SOCKET | 12 | |
| 9T3871 | 34 SEAL-RECTANGULAR | 1 | |
| 9T3872 | 35 SEAL-RECTANGULAR | 1 | |
| 8T8442 | 36 BOLT-SOCKET HEAD | 1 | |
| 9T3941 | 37 PLUG-BREAKOFF | 2 | |
| 9S8004 | 38 PLUG-O-RING | 1 | |
| 9T3049 | 39 BOLT-STOP | 1 | |
| 3J1907 | 40 SEAL | 1 | |
| 5F9144 | 41 SEAL-O-RING (SMALL) | 1 | |
| 2D0598 | SEAL-O-RING (LARGE) | 1 |
