System And Components
5N-8761 DRIVE GP-FANS/N 11N7828-99999
Group No: 5N-8761
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N6490 | 1 BRACKET AS-FAN | 1 | |
| 4N0684 | 1A DOWEL | 1 | |
| 1P9946 | 1B SHAFT-FAN | 1 | |
| 9N5120 | 2 BRACKET | 1 | |
| 0S1594 | 3 BOLT (3/8-16X1-IN) | 2 | |
| 4N2372 | 4 ADAPTER-BRACKET | 1 | |
| 9L4238 | 5 BOLT (3/8-16X8.5-IN) | 1 | |
| 1D4566 | 6 BOLT (1/2-13X3.5-IN) | 2 | |
| 2P9084 | 7 STUD-TAPERLOCK (1/2-13X0.83-IN, 1/2-13X0.98-IN) | 2 | |
| 7D1649 | 8 WASHER-HARD (13.5X32X5-MM THK) | 4 | |
| 1F7958 | 9 NUT-FULL (1/2-13-THD) | 2 | |
| 7N8827 | 10 HUB | 1 | |
| 5S9062 | 11 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 5S2106 | 12 SEAL-LIP TYPE | 1 | |
| 8H9789 | 13 BALL BEARING (35MM X 72MM X 17MM THK) | 1 | |
| 8N5305 | 14 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 3L1425 | 15 BALL BEARING (35MM X 80MM X 21MM THK) | 1 | |
| 7N2900 | 16 RETAINER | 1 | |
| 5P7979 | 17 BOLT-LOCKING (5/16-24X2.25-IN) | 2 | |
| 9F4446 | 18 SEAL-O-RING | 1 | |
| 4N2370 | 19 ADAPTER-FAN | 1 | |
| 2D4867 | 20 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 4N6289 | 21 PULLEY-FAN DRIVE (3-GROOVE) | 1 | |
| 0L2070 | 22 BOLT (3/8-16X2.25-IN) | 6 | |
| 4B4550 | 23 FITTING-PRESSURE RELIEF (1/8-27 PTF) | 1 |
