System And Components
109-7438 ENGINE GPS/N 6ED363-440
Group No: 109-7438
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T9382 | 1 BOLT (7/16-14X1.25-IN) | 12 | |
| 8T5360 | 2 WASHER (12X22.5X2.5-MM THK) | 12 | |
| 5E8171 | 3 HANDLE | 1 | |
| 1G9829 | 4 LEVER AS | 1 | |
| 5C6266 | 5 BOLT (5/8-11X1-IN) | 6 | |
| 8T4122 | 6 WASHER-HARD (17X32X3.5-MM THK) | 29 | |
| 0980647 | 7 FLANGE | 1 | |
| 0776019 | 8 SETSCREW | 2 | |
| 3E3636 | 9 SWITCH AS-BALL (NEUTRAL START) | 1 | |
| 3E3376 | RECEPTACLE AS-CONNECTOR (4-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 1G8922 | 10 PLATE AS | 1 | |
| 0775973 | 11 CLUTCH GP-POWER TAKE-OFF | 1 | |
| 8T8917 | 12 BOLT (1/2-13X1.25-IN) | 8 | |
| 8T4223 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 4B1232 | 14 SCREW-MACHINE (10-24X0.75-IN) | 2 | |
| 0S1591 | 15 BOLT (3/8-16X1.5-IN) | 1 | |
| 0310249 | 16 LOCKNUT (10-24-THD) | 2 | |
| 0339497 | 17 CLAMP | 1 | |
| 0339498 | 18 SHIM | 1 | |
| 4M0061 | 19 BOLT (5/16-18X0.75-IN) | 2 | |
| 0822159 | 20 BRACKET-THROTTLE | 1 | |
| 7X0345 | 21 BOLT (5/8-11X1.75-IN) | 12 | |
| 5E8086 | 22 MOUNT-ENGINE | 2 | |
| 8T3425 | 23 CHANNEL-TRIM | ||
| 7X0347 | 24 BOLT (5/8-11X2.25-IN) | 8 | |
| 3E9861 | 25 LOCKNUT (5/8-11-THD) | 8 | |
| 0780287 | 26 PUMP GP-VANE | 1 | |
| 8T8919 | 27 BOLT (1/2-13X1.75-IN) | 2 | |
| 7X0332 | 28 BOLT (1/2-13X4.5-IN) | 1 | |
| 7X8958 | 29 SPACER | 1 | |
| 6F5281 | 30 BOLT (1/2-13X10-IN) | 1 | |
| 7X8959 | 31 SPACER | 1 | |
| 9X0941 | 32 LOCKNUT (1/2-13-THD) | 1 | |
| 8T8924 | 33 BOLT (3/4-10X2.5-IN) | 2 | |
| 8T4994 | 34 WASHER-HARD (20X36.5X3.5-MM THK) | 2 | |
| 3E9862 | 35 LOCKNUT (3/4-10-THD) | 2 | |
| 2P8454 | 36 BOLT (5/8-11X1.5-IN) | 4 | |
| 5E8109 | 37 ADAPTER | 1 | |
| 9B7237 | 38 BOLT (3/8-16X1.25-IN) | 6 | |
| 8T4896 | 39 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 4N2571 | 40 SPIDER AS-FAN (6-BLADE) | 1 | |
| 6N5926 | 41 SENDER AS-TEMPERATURE (COOLANT) | 1 | |
| 5L8484 | 42 GASKET | 1 | |
| 7X8965 | 43 GUARD | 1 | |
| 3K2889 | 44 LOCKNUT (5/8-11-THD) | 4 | |
| 5E8090 | 45 PIPE-EXHAUST | 1 | |
| 4L6452 | 46 BALL JOINT | 1 | |
| 6T7663 | 47 SWITCH AS (EMS OIL PRESSURE) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 0817707 | 48 STARTING MOTOR GP-ELECTRIC | 1 | |
| 8S2332 | 49 BOLT-12 POINT HEAD (5/8-11X1.75-IN) | 3 | |
| 3B7721 | 50 BUSHING-REDUCER | 1 | |
| 0302010 | 51 SENDER AS-PRESSURE (OIL) | 1 | |
| 4B2049 | NUT (10-32-THD) | 1 | |
| 8F1434 | LOCKWASHER | 1 | |
| 8T0328 | WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 3B7722 | 52 BUSHING-PIPE | 1 | |
| 2P1279 | 53 LOCKNUT (9/16-18-THD) | 1 | |
| 3B8488 | 54 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 0980501 | 55 KEY | 1 |
