System And Components
109-7439 AIR CLEANER GPS/N 6ED363-367
Group No: 109-7439
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3K6060 | 1 LOCKNUT (3/8-16-THD) | 10 | |
| 5P1075 | 2 WASHER-HARD (10.2X22.5X3-MM THK) | 14 | |
| 1094470 | 3 PLATE | 1 | |
| 5L2534 | 4 U-BOLT | 1 | |
| 1094468 | 5 TUBE AS | 1 | |
| 4L6454 | 6 BOLT (3/8-16X1-IN) | 4 | |
| 7R8742 | 7 U-BOLT | 1 | |
| 8T4224 | 8 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 3E9860 | 9 LOCKNUT (5/16-18-THD) | 2 | |
| 0821116 | 10 TUBE | 2 | |
| 5P3860 | 11 CLAMP-HOSE | 6 | |
| 7X2153 | 12 HOSE | 2 | |
| 8C3121 | 13 BOLT (5/16-18X1.5-IN) | 2 | |
| 5E8089 | 14 SUPPORT | 1 | |
| 6T6158 | 15 ELBOW | 1 | |
| 0663454 | 16 INDICATOR (AIR RESTRICTION) | 1 | |
| 3B6552 | 17 ELBOW-PIPE | 1 | |
| 5L3233 | 18 FITTING-CONNECTOR | 1 | |
| 1074869 | 19 BAND-AIR CLEANER | 2 | |
| 1T0822 | 20 BOLT-12 POINT HEAD (3/8-16X0.75-IN) | 2 | |
| 7N5974 | 21 PRECLEANER GP | 1 | |
| 5P1471 | 22 HOSE (28CM) | ||
| 5P0597 | 23 CLAMP-HOSE | 2 | |
| 1W0078 | 24 ADAPTER AS | 1 | |
| 1P9390 | 25 GASKET-OUTLET | 1 | |
| 2K4973 | 26 LOCKNUT (3/8-16-THD) | 10 | |
| 6N1681 | 27 AIR CLEANER GP | 1 | |
| 1P8481 | CUP AS-AIR CLEANER | 1 | |
| 6N7692 | GASKET | 1 | |
| 1P8482 | FILTER ELEMENT AS-AIR (SECONDARY) | 1 | |
| 7W5313 | FILTER ELEMENT AS-AIR (PRIMARY)(AIR) | 1 | |
| 3S4115 | BOLT AS | 2 | |
| 6V8189 | 28 NUT (5/16-18-THD) | 2 | |
| 9B7237 | 29 BOLT (3/8-16X1.25-IN) | 6 |
