System And Components
122-6801 CONTROL GP-WATERS/N 6ED363-440
Group No: 122-6801
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E6477 | 1 RELAY AS (24-VOLT)(FORWARD/REVERSE) | 1 | |
| 2N3479 | 2 SCREW (10-24X0.5-IN) | 1 | |
| 4B4274 | 3 WASHER (5.5X13X1.2-MM THK) | 1 | |
| 0310249 | 4 LOCKNUT (10-24-THD) | 1 | |
| 1210275 | 5 CONNECTOR | 1 | |
| 1470856 | 6 RESISTOR AS | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T5346 | TUBE-HEAT SHRINK (19.1-MM DIA)(5 CM) | ||
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 4D7794 | 7 CLIP | 6 | |
| 8T4224 | 8 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T5391 | 9 BOLT (5/16-18X0.5-IN) | 1 | |
| 5M3062 | 10 BOLT (3/8-16X0.75-IN) | 1 | |
| 8T4896 | 11 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 1219807 | 12 HARNESS AS | 1 | |
| 1S9593 | STRAP-CABLE | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 3 | |
| 7G7917 | PLUG-SEAL | 20 | |
| 7T6365 | HOUSING-RECEPTACLE | 1 | |
| 8N1514 | PLUG AS-CONNECTOR (37-PIN) | 1 | |
| 8N1521 | BELL AS-END | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 9D5424 | CONNECTOR | 1 | |
| 1126944 | 13 CONTROL GP | 1 | |
| 1187592 | 14 BRACKET AS | 1 | |
| 6V8801 | 15 NUT (3/8-16-THD) | 3 | |
| 7X0618 | 16 WASHER-HARD (13.5X40X5-MM THK) | 4 | |
| 2H3788 | 17 LOCKNUT (1/2-13-THD) | 4 | |
| 7G7053 | 18 GROMMET | 4 | |
| 5P8502 | 19 PADLOCK GP | 1 | |
| 5P8500 | KEY | 1 | |
| 4L6454 | 21 BOLT (3/8-16X1-IN) | 3 | |
| 1S9593 | 22 STRAP-CABLE | 25 |
