System And Components
104-9829 PUMP & METER GPS/N 6ED363-440
Group No: 104-9829
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V8188 | 1 NUT (1/2-13-THD) | 20 | |
| 7R2954 | 2 COVER | 1 | |
| 7X4280 | 3 BASKET | 1 | |
| 1093052 | 4 HOUSING-STRAINER | 1 | |
| 8T9383 | 5 BOLT (1/2-13X0.75-IN) | 12 | |
| 8T4223 | 6 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 1093053 | 7 PUMP-BODY | 1 | |
| 1093054 | 8 PISTON | 1 | |
| 1093055 | 9 SHUTTLE | 1 | |
| 4L9337 | 10 BOLT (3/8-16X1.5-IN) | 4 | |
| 1093056 | 11 BLOCK-FLOW ADJUSTMENT | 1 | |
| 1093058 | 12 COVER | 1 | |
| 1093059 | 13 ROTOR | 1 | |
| 8C7139 | 14 KEY | 1 | |
| 8T8919 | 15 BOLT (1/2-13X1.75-IN) | 32 | |
| 1093060 | 16 COVER-DRIVE | 1 | |
| 5P3881 | 17 SEAL-O-RING | 1 | |
| 8T8917 | 18 BOLT (1/2-13X1.25-IN) | 2 | |
| 7X4286 | 19 MOTOR GP-GEROTOR | 1 | |
| 7R3002 | 20 COVER | 1 | |
| 6F5926 | 21 NUT | 1 | |
| 1093061 | 22 BODY | 1 | |
| 8J2413 | 23 SEAL-O-RING | 1 | |
| 7X4279 | 24 SENSOR GP-SPEED | 1 | |
| 8T9382 | 25 BOLT (7/16-14X1.25-IN) | 4 | |
| 2N1365 | 26 SEAL-STUD | 4 | |
| 2H3776 | 27 LOCKNUT | 1 | |
| 7R6151 | 28 BRACKET | 1 | |
| 7R3004 | 29 ELEMENT AS-MEASURING | 1 | |
| 7X4235 | 30 DISC | 1 |
