System And Components
1G-5712 SPRAY GP-WATER & ADDITIVES/N 6ED363-440
Group No: 1G-5712
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0016304 | 1 ELBOW | 1 | |
| 5E9278 | 2 HOSE AS | 1 | |
| 0321523 | 3 ELBOW-FLARED | 1 | |
| 0308494 | 4 HOSE AS | 1 | |
| 3V4655 | 5 HOSE AS | 1 | |
| 6K1972 | 6 ELBOW-FLARED | 2 | |
| 1F3605 | 7 BUSHING-REDUCER | 2 | |
| 0818492 | 8 HOSE AS | 2 | |
| 3K6060 | 9 LOCKNUT (3/8-16-THD) | 5 | |
| 3B7277 | 10 NIPPLE-PIPE | 1 | |
| 8T4896 | 11 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 9B7237 | 12 BOLT (3/8-16X1.25-IN) | 4 | |
| 4L6454 | 13 BOLT (3/8-16X1-IN) | 4 | |
| 1G5384 | 14 BRACKET AS | 1 | |
| 1G8837 | 15 VALVE GP-CONTROL (SPRAY CONTROL) | 1 | |
| 5P4325 | 16 CLIP (LOOP) | 2 | |
| 7X4269 | 17 COCK | 1 | |
| 5E9255 | 18 CHAIN | 1 | |
| 3K0360 | 19 SEAL-O-RING | 2 | |
| 8C2005 | 20 FILTER-OIL (ASPHALT SPRAY PUMP) | 1 | |
| 5P5007 | 21 REDUCER | 2 | |
| 3B6556 | 22 ELBOW-STREET | 2 | |
| 0308309 | 23 CONNECTOR | 2 | |
| 0307948 | 24 ELBOW | 2 | |
| 5E9282 | 25 HOSE AS | 1 | |
| 0060315 | 26 TEE-FLARED | 1 | |
| 9S8896 | 27 CAP (FLARED 37-DEG) | 1 | |
| 9N9988 | 28 PLUG | 1 | |
| 1082474 | 29 TEE | 1 | |
| 2M9780 | 30 SEAL-O-RING | 3 | |
| 6K6307 | 31 SEAL-O-RING | 1 | |
| 7M8485 | 32 SEAL-O-RING | 1 | |
| 6K3461 | 33 CONNECTOR | 1 | |
| 0307965 | 34 ELBOW | 1 | |
| 7X0338 | 35 BOLT (1/2-13X6-IN) | 1 | |
| 1P0043 | 36 NUT-FLARED (1-5/16-12-THD) | 1 | |
| 5E9279 | 37 BRACKET | 1 | |
| 5E9280 | 38 SHEAVE AS | 1 | |
| 8C1092 | 39 V-BELT | 3 | |
| 0818081 | 40 SHEAVE | 1 | |
| 0818091 | 41 BASE | 1 | |
| 1B4430 | 42 NUT-JAM (1/2-20-THD) | 1 | |
| 5E9281 | 43 BOLT | 1 | |
| 0676684 | 44 REDUCER-FLARED | 1 | |
| 1C4226 | 45 ELBOW | 1 | |
| 7X4246 | 46 PUMP GP-HYDRAULIC | 1 | |
| 0307950 | 47 ELBOW | 2 | |
| 0310250 | 48 NUT (1/4-20-THD) | 5 | |
| 0307951 | 49 ELBOW-FLARED | 1 | |
| 0684174 | 50 ELBOW | 2 | |
| 2H3788 | 51 LOCKNUT (1/2-13-THD) | 3 | |
| 7D0978 | 52 TEE | 1 | |
| 9S4183 | 53 PLUG (1-1/16-12-THD) | 1 | |
| 8T4205 | 54 WASHER-HARD (7.2X14.5X2-MM THK) | 10 | |
| 5P4481 | 55 ADAPTER-O-RING | 1 | |
| 7X0266 | 56 BOLT (1/4-20X3-IN) | 2 | |
| 3J7354 | 57 SEAL-O-RING | 1 | |
| 0307946 | 58 ELBOW | 1 | |
| 8T4122 | 59 WASHER-HARD (17X32X3.5-MM THK) | 7 | |
| 8T9393 | 60 BOLT (5/8-11X1.5-IN) | 4 | |
| 0382238 | 61 HOSE AS | 1 | |
| 1G8086 | 62 VALVE GP-PROPORTIONAL (ASPHALT FLOW ADJUSTMENT) | 1 | |
| 9N7655 | 63 HOSE AS | 1 | |
| 3D2824 | 64 SEAL-O-RING | 3 | |
| 1H3337 | 65 BOLT (1/4-20X0.875-IN) | 3 | |
| 8T5494 | 66 HOSE AS | 1 | |
| 0015744 | 67 ELBOW-FLARED | 1 | |
| 5P5005 | 68 REDUCER-FLARED | 1 | |
| 1G5385 | 69 BRACKET AS | 1 | |
| 3R9704 | 70 ELBOW | 2 | |
| 4M6424 | 71 BOLT (5/16-18X3-IN) | 2 | |
| 8T4224 | 72 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 2R0504 | 73 NUT (5/16-18-THD) | 2 | |
| 8T4223 | 74 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6R0050 | 75 ELBOW | 1 |
