System And Components
398-3596 BELT TIGHTENER GPS/N RTL1-116
Group No: 398-3596
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4314097 | 1 BRACKET | 1 | |
| 2M2742 | 2 PLATE-RETAINER | 1 | |
| 4D1326 | 3 LOCKWASHER | 1 | |
| 7E4808 | 4 PLATE | 1 | |
| 8C5238 | 5 SEAL-V-RING | 1 | |
| 8N9409 | 6 COVER | 1 | |
| 3512196 | 7 SPACER-SPECIAL | 1 | |
| 3766589 | 8 SPRING | 2 | |
| 3941200 | 9 BUSHING | 1 | |
| 4244489 | 10 PULLEY | 1 | |
| 4790857 | 11 ARM AS | 1 | |
| 4S5367 | 11A BUSHING AS (MOUNT) | 1 | |
| 5M7937 | DOWEL | 1 | |
| 0S1594 | 12 BOLT (3/8-16X1-IN) | 1 | |
| 0S1617 | 13 BOLT (5/16-18X0.75-IN) | 4 | |
| 2838650 | 14 WASHER-HARD (10.2X18.5X5-MM THK) | 2 | |
| 2N8374 | 15 GASKET | 1 | |
| 3332408 | 16 BALL BEARING | 2 | |
| 3B4617 | 17 PIN-COTTER | 2 | |
| 6C3241 | 18 BOLT (1/2-13X1.5-IN) | 1 | |
| 5P8245 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6H3956 | 20 PIN | 1 | |
| 8B1419 | 21 PIN-CLEVIS | 2 | |
| 8T4896 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 9B7237 | 23 BOLT (3/8-16X1.25-IN) | 2 | |
| 9M1974 | 24 WASHER-HARD (8.8X16X2-MM THK) | 4 |
