System And Components
447-5860 DRIVE GP-AUXILIARYS/N WHD1-UP
Group No: 447-5860
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5L5840 | 1 WASHER (9.25X16.92X1.83-MM THK) | 1 | |
| 6V0405 | 2 SEAL-BONDED | 2 | |
| 7C3258 | 3 WASHER AS-THRUST | 1 | |
| 7N2047 | DOWEL | 1 | |
| 7N7539 | 4 WASHER-THRUST | 2 | |
| 2353546 | 5 SEAL-O-RING | 1 | |
| 4244893 | 6 SHAFT AS-PUMP DRIVE | 1 | |
| 1150591 | 6A BUSHING | 1 | |
| 4401134 | 7 COVER AS | 1 | |
| 1275400 | 7A BUSHING | 1 | |
| 8T6757 | PLUG-PIPE | 1 | |
| 5700440 | 8 ADAPTER AS | 1 | |
| 1275400 | 8A BUSHING | 1 | |
| 8T6759 | PLUG-PIPE | 2 | |
| 0T0055 | 9 BOLT (3/8-16X4.25-IN) | 1 | |
| 3555732 | 10 GEAR AS-IDLER (42-TEETH) | 1 | |
| 1409597 | 10A BUSHING | 1 | |
| 3572432 | 11 SHAFT-IDLER | 1 | |
| 1T0720 | 12 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 5 | |
| 2594598 | 13 SEAL-O-RING | 2 | |
| 2B2695 | 14 BOLT (5/16-18X0.875-IN) | 4 | |
| 4K5175 | 15 BOLT-12 POINT HEAD (1/2-13X1.5-IN) | 16 | |
| 3700013 | 16 GEAR-WATER PUMP DRIVE (54-TEETH) | 1 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 5P0840 | 18 SEAL-O-RING | 1 | |
| 5P8245 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V3348 | 20 SEAL-O-RING | 1 | |
| 1D4572 | 21 BOLT (1/2-13X5.5-IN) | 2 | |
| 3B1915 | 22 BOLT (3/8-16X1.375-IN) | 6 |
