System And Components
448-2418 DRIVE GP-FANS/N RTL1-103
Group No: 448-2418
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8686 | 1 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 6U1989 | 2 VALVE-RELIEF | 1 | |
| 7E4202 | 3 WASHER-HARD (16.2X30X5-MM THK) | 3 | |
| 7W7282 | 4 PULLEY-FAN DRIVE | 1 | |
| 9Y2647 | 5 HUB-FAN PULLEY | 1 | |
| 2095296 | 6 SPACER (63.6X76.2X76.2-MM THK) | 1 | |
| 2885859 | 7 HOSE AS | 1 | |
| 4250545 | 8 BRACKET AS | 1 | |
| 4481936 | 9 V-BELT SET (INCLUDES 5-BELTS) | 1 | |
| 4620801 | 10 STUD | 2 | |
| 4669950 | 11 WASHER-RETAINING | 1 | |
| 4711020 | 12 ADAPTER | 1 | |
| 4867516 | 13 BRACKET AS-FAN | 1 | |
| 0S1594 | 14 BOLT (3/8-16X1-IN) | 2 | |
| 0S1621 | 15 BOLT (1/2-13X1-IN) | 1 | |
| 0T0573 | 16 BOLT (3/8-16X2.75-IN) | 12 | |
| 1327551 | 17 SPACER (11X19X6-MM THK) | 1 | |
| 1D4572 | 18 BOLT (1/2-13X5.5-IN) | 4 | |
| 1F7958 | 19 NUT-FULL (1/2-13-THD) | 2 | |
| 1J4034 | 20 SEAL-LIP TYPE | 1 | |
| 3537955 | 21 GROMMET | 1 | |
| 3B1915 | 22 BOLT (3/8-16X1.375-IN) | 8 | |
| 3B6552 | 23 ELBOW-PIPE | 1 | |
| 5F3144 | 24 SEAL-O-RING | 1 | |
| 5M2894 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 5P8245 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 17 | |
| 5P9085 | 27 CLIP (LOOP) | 1 | |
| 6Y7651 | 28 CONE-BEARING | 2 | |
| 6Y7652 | 29 CUP-BEARING (TAPERED ROLLER) | 2 | |
| 7K4370 | 30 BOLT (5/8-11X1.75-IN) | 3 | |
| 7X7730 | 31 PLUG-PIPE | 1 | |
| 8S3887 | 32 BOLT (1/2-13X11-IN) | 2 | |
| 8T1887 | 33 CLIP (SLOT) | 1 | |
| 8T1888 | 34 CLIP (TAB) | 1 | |
| 9S1366 | 35 BOLT (1/2-13X2.5-IN) | 8 |
