System And Components
423-3679 GEAR GP-FRONTS/N WHD1-128
Group No: 423-3679
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5R7136 | 1 WASHER-SEALING | 1 | |
| 5R7137 | 2 WASHER-SEALING | 2 | |
| 7C3258 | 3 WASHER AS-THRUST | 1 | |
| 7N2047 | 3A DOWEL | 1 | |
| 7N5245 | 4 ADAPTER AS-PUMP | 1 | |
| 1275400 | 4A BUSHING | 1 | |
| 7N5246 | 5 WASHER-THRUST | 2 | |
| 2353546 | 6 SEAL-O-RING | 1 | |
| 0S1590 | 7 BOLT (3/8-16X2-IN) | 5 | |
| 0S1594 | 8 BOLT (3/8-16X1-IN) | 2 | |
| 3913108 | 9 GEAR-CRANKSHAFT (72-TEETH) | 1 | |
| 3555732 | 10 GEAR AS-IDLER (42-TEETH) | 1 | |
| 1409597 | 10A BUSHING | 1 | |
| 3572432 | 11 SHAFT-IDLER | 1 | |
| 0T0055 | 12 BOLT (3/8-16X4.25-IN) | 1 | |
| 3665349 | 13 ADAPTER AS | 1 | |
| 1275400 | 13A BUSHING | 1 | |
| 3670069 | 14 SHAFT AS-AUXILIARY DRIVE | 1 | |
| 8T2153 | 14A SETSCREW-SOCKET (1/4-28X0.31-IN) | 1 | |
| 1D4572 | 15 BOLT (1/2-13X5.5-IN) | 2 | |
| 3700013 | 16 GEAR-WATER PUMP DRIVE (54-TEETH) | 1 | |
| 2594598 | 17 SEAL-O-RING | 2 | |
| 3S1307 | 18 BOLT-12 POINT HEAD (3/8-16X2-IN) | 20 | |
| 4B3388 | 19 BOLT (5/16-18X1.125-IN) | 4 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5P8245 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V3348 | 22 SEAL-O-RING | 1 | |
| 9M1974 | 23 WASHER-HARD (8.8X16X2-MM THK) | 4 |
