System And Components
457-0071 HOUSING GP-FLYWHEELS/N WHD1-UP
Group No: 457-0071
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5771766 | 1 WASHER-SEALING | 14 | |
| 5771767 | 2 WASHER-SEALING | 16 | |
| 4175424 | 3 SEAL | 1 | |
| 4570070 | 4 HOUSING AS-FLYWHEEL | 1 | |
| 3F6795 | DOWEL | 3 | |
| 3F6808 | DOWEL | 1 | |
| 7N2047 | DOWEL | 3 | |
| 0S1595 | 5 BOLT (1/2-13X1.25-IN) | 1 | |
| 1D4574 | 6 BOLT (1/2-13X6-IN) | 7 | |
| 1D4597 | 7 BOLT (5/8-11X6.5-IN) | 1 | |
| 5D9514 | 8 BOLT (5/8-11X6.25-IN) | 13 | |
| 5P4626 | 9 BOLT (5/8-11X10.5-IN) | 2 | |
| 5P8245 | 10 WASHER-HARD (13.5X25.5X3-MM THK) | 14 | |
| 5P8247 | 11 WASHER-HARD (17X32X3.5-MM THK) | 14 | |
| 8T4122 | 12 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 8T6763 | 13 PLUG-PIPE (1/4-18-THD) | 5 | |
| 8T6765 | 14 PLUG-PIPE (1/4-18-THD) | 1 | |
| 2B0947 | 15 BOLT (1/2-13X2.25-IN) | 8 |
