System And Components
450-8942 LINES GP-AIR COMPRESSORS/N WHD1-UP
Group No: 450-8942
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0693 | 1 CLAMP AS | 2 | |
| 1081434 | GROMMET | 2 | |
| 7V0916 | 2 HOSE AS | 1 | |
| 7W9834 | 3 VALVE-REGULATOR | 1 | |
| 8J0135 | 4 PLUG | 1 | |
| 1326782 | 5 BRACKET | 1 | |
| 1666368 | 6 ELBOW AS | 1 | |
| 6V5063 | SEAL-O-RING | 1 | |
| 0050658 | ELBOW-FLARED | 1 | |
| 1981287 | 7 TUBE AS | 1 | |
| 2301072 | 8 GASKET | 1 | |
| 3261887 | 9 FLANGE | 1 | |
| 4303326 | 10 TUBE AS | 1 | |
| 4508944 | 11 HOSE AS-WATER | 1 | |
| 4866730 | 12 HOSE & TUBE AS | 1 | |
| 4866748 | 13 PLATE | 1 | |
| 0307949 | 14 ELBOW | 1 | |
| 0307972 | 15 ELBOW | 1 | |
| 0321269 | 16 ELBOW | 3 | |
| 0616717 | 17 ELBOW-FLARED | 1 | |
| 0L1351 | 18 BOLT (3/8-16X0.875-IN) | 1 | |
| 1653931 | 19 BOLT (3/8-16X1.75-IN) | 1 | |
| 1653929 | 20 BOLT (3/8-16X1.5-IN) | 2 | |
| 0T0573 | 21 BOLT (3/8-16X2.75-IN) | 1 | |
| 1A2029 | 22 BOLT (3/8-16X1.125-IN) | 1 | |
| 3537952 | 23 GROMMET | 1 | |
| 4S6399 | 24 CONNECTOR | 1 | |
| 5M2894 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5P4479 | 26 ELBOW (FLARED-LONG) | 1 | |
| 6V3251 | 27 SEAL-O-RING | 1 | |
| 7K9197 | 28 ELBOW | 1 | |
| 7W3447 | 29 SPACER (10.2X19.05X10.2-MM THK) | 1 | |
| 8M7065 | 30 GASKET (AIR INLET) | 1 | |
| 8M8162 | 31 BOLT-12 POINT HEAD (5/16-18X1.5-IN) | 2 | |
| 8T1897 | 32 CLIP (SLOT) | 1 | |
| 8T1898 | 33 CLIP (TAB) | 1 | |
| 9L5254 | 34 ELBOW | 1 | |
| 9M1974 | 35 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9M6522 | 36 CONNECTOR (1/2-14 NPTF) | 1 | |
| 9S8752 | 37 NUT-FULL (3/8-16-THD) | 1 | |
| 9X6458 | 38 WASHER-HARD (10.2X22.5X3-MM THK) | 1 |
