423-7733 LINES GP-ENGINE OILS/N WHD1-120

Group No: 423-7733
Part NumberPart NameQty
1W24471 ADAPTER-OUTLET1
2W10532 PLUG1
2W16353 SPRING1
6B92024 SPRING2
7N76975 PLUNGER AS (SEQUENCE VALVE)2
7M1808DOWEL1
8N29296 COVER2
10080757 CLAMP AS1
10542998 TUBE AS1
12442739 VALVE-BYPASS1
136329610 FLANGE1
146735911 TUBE1
150661212 ELBOW-OUTLET1
153996313 RING2
191669514 PLATE1
237762315 SEAL-O-RING2
244586716 ELBOW1
245684817 CLAMP AS4
247480618 ELBOW1
264045019 CLAMP AS1
1F0750NUT-WELD (3/8-16-THD)2
338860320 RING-RETAINING1
359412221 ELBOW1
359412322 ADAPTER (TURBOCHARGER OIL)1
361709723 RING1
361709824 FLANGE1
0L114325 BOLT (3/8-16X2.5-IN)2
165393126 BOLT (3/8-16X1.75-IN)8
165392827 BOLT (3/8-16-THD)12
165392928 BOLT (3/8-16X1.5-IN)2
0S159429 BOLT (3/8-16X1-IN)4
0T006530 BOLT (3/8-16X3.5-IN)4
0T057331 BOLT (3/8-16X2.75-IN)4
109233232 SEAL-O-RING2
1A202933 BOLT (3/8-16X1.125-IN)8
1A596434 BOLT (3/8-16X4.5-IN)4
228709735 SEAL-O-RING1
2K497336 LOCKNUT (3/8-16-THD)2
3M704537 PLUG (3/4-14 NPT-THD)1
3P065338 SEAL-O-RING1
269788539 SEAL-O-RING1
3S154640 NUT-FULL (7/16-14-THD)4
4B314041 COVER1
4F896542 BOLT (7/16-14X1.125-IN)4
5M289443 WASHER-HARD (10.2X18.5X2.5-MM THK)34
5P489244 SEAL-O-RING1
5P584645 SEAL-O-RING1
5P824446 WASHER-HARD (12X22.5X2.5-MM THK)8
6B093347 SPACER (10.31X19.05X6.35-MM THK)4
6J224448 SEAL-O-RING1
6V157249 CLIP (SLOT)2
6V157350 CLIP (TAB)2
6V157451 GROMMET2
6V390852 SEAL-O-RING1
447720653 SEAL-O-RING4
6V504854 SEAL-O-RING1
238508055 SEAL-O-RING1
8C310756 SEAL-O-RING1
8C344557 CAP-DUST1
8C344658 VALVE-SAMPLING1
8M902459 WASHER-HARD (10.2X22.5X5-MM THK)4
9S418560 PLUG (3/4-16-THD)1
