System And Components
510-0835 LINES GP-TURBOCHARGER OILS/N WHD1-UP
Group No: 510-0835
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W0752 | 1 GASKET | 4 | |
| 4P0692 | 2 CLAMP AS | 16 | |
| 1081434 | GROMMET | 1 | |
| 7E5330 | 3 BRACKET | 8 | |
| 2501496 | 4 ELBOW | 2 | |
| 2673393 | 5 BRACKET | 2 | |
| 3535133 | 6 ELBOW AS | 1 | |
| 0307949 | ELBOW | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3650576 | 7 CONNECTOR AS | 1 | |
| 9M4584 | CONNECTOR | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3928009 | 8 ELBOW-DRAIN | 4 | |
| 4684367 | 9 TUBE AS | 2 | |
| 4849543 | 10 HOSE AS | 4 | |
| 4849544 | 11 TUBE AS | 1 | |
| 4849545 | 12 TUBE AS | 1 | |
| 4849546 | 13 TUBE AS | 2 | |
| 4849547 | 14 TUBE AS | 4 | |
| 5100836 | 15 HOSE AS-OIL | 2 | |
| 5212595 | 16 HOSE AS-OIL | 2 | |
| 5234585 | 17 TUBE AS | 2 | |
| 0038581 | 18 TEE-UNION | 2 | |
| 0L1143 | 19 BOLT (3/8-16X2.5-IN) | 8 | |
| 0S1617 | 20 BOLT (5/16-18X0.75-IN) | 6 | |
| 1886126 | 21 GASKET | 4 | |
| 1A9579 | 22 BOLT (5/16-18X1.5-IN) | 2 | |
| 1B2790 | 23 BOLT (5/16-18X1.375-IN) | 8 | |
| 1S6595 | 24 GASKET-OIL SUPPLY | 4 | |
| 2287092 | 25 SEAL-O-RING | 4 | |
| 3218648 | 26 CONNECTOR AS | 4 | |
| 2T2991 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385083 | SEAL-O-RING | 1 | |
| 3537952 | 27 GROMMET | 2 | |
| 3B1915 | 28 BOLT (3/8-16X1.375-IN) | 18 | |
| 3E4352 | 29 WASHER-HARD (8.8X20.5X2.5-MM THK) | 8 | |
| 5M2894 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 5P8228 | 31 REDUCER-FLARED | 4 | |
| 8M9124 | 32 WASHER (10X22.5X8-MM THK) | 2 | |
| 8S0023 | 33 CLIP (SLOT) | 2 | |
| 8S0024 | 34 CLIP (TAB) | 2 | |
| 9C5344 | 35 SPACER (10.5X20X18-MM THK) | 2 | |
| 9M1974 | 36 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9S8752 | 37 NUT-FULL (3/8-16-THD) | 10 | |
| 9X6458 | 38 WASHER-HARD (10.2X22.5X3-MM THK) | 20 |
