System And Components
267-2180 AIR CLEANER GPS/N RTL104-UP
Group No: 267-2180
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2M0879 | 1 SEAL-O-RING | 3 | |
| 2W9069 | 2 CUP AS-PRECLEANER | 3 | |
| 1S5465 | GUARD-DUST | 1 | |
| 1S5485 | VALVE-DUST | 1 | |
| 9M7959 | CLAMP-HOSE | 1 | |
| 1953815 | SEAL | 1 | |
| 5N7834 | 3 CLAMP AS | 3 | |
| 7E7377 | 4 GASKET | 2 | |
| 7W9857 | 5 GASKET | 2 | |
| 8T0649 | 6 BOLT (M16X2X110-MM) | 6 | |
| 1842515 | 7 NUT-HEX FLANGE (M10X1.5-THD) | 20 | |
| 2162632 | 8 ROD-HOLDING | 4 | |
| 2162634 | 9 CHAIN | 2 | |
| 2673005 | 10 FILTER ELEMENT AS-AIR (SECONDARY) | 2 | |
| 2777836 | 11 COVER AS | 2 | |
| 4199162 | 12 FILTER ELEMENT AS-AIR (PRIMARY) | 2 | |
| 4897663 | 13 CLIP | 8 | |
| 5253362 | 14 SHIELD AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 5253363 | 15 SHIELD AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 5253364 | 16 SHIELD AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 8T4136 | 17 BOLT (M10X1.5X25-MM) | 22 | |
| 1268472 | 18 SEAL (61-CM EACH) |
