System And Components
433-2902 AIR CLEANER GPS/N RTL1-103
Group No: 433-2902
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2M0879 | 1 SEAL-O-RING | 3 | |
| 2W9069 | 2 CUP AS-PRECLEANER | 3 | |
| 1S5465 | GUARD-DUST | 1 | |
| 1S5485 | VALVE-DUST | 1 | |
| 9M7959 | CLAMP-HOSE | 1 | |
| 1953815 | SEAL | 1 | |
| 5N7834 | 3 CLAMP AS | 3 | |
| 7E7377 | 4 GASKET | 2 | |
| 7W9857 | 5 GASKET | 2 | |
| 2162632 | 6 ROD-HOLDING | 4 | |
| 2162634 | 7 CHAIN | 2 | |
| 2673005 | 8 FILTER ELEMENT AS-AIR (SECONDARY) | 2 | |
| 2777836 | 9 COVER AS | 2 | |
| 3812704 | 10 KIT-CLIP | 8 | |
| 4199162 | 11 FILTER ELEMENT AS-AIR (PRIMARY) | 2 | |
| 4351231 | 12 SHIELD-RAIN | 2 | |
| 4351232 | 13 SHIELD-RAIN | 2 | |
| 4351234 | 14 PLATE | 1 | |
| 1757141 | 15 NUT-HEX FLANGE (M10X1.5-THD) | 34 | |
| 8T4136 | 16 BOLT (M10X1.5X25-MM) | 22 | |
| 8T4779 | 17 BOLT (M16X2X35-MM) | 3 | |
| 9X8257 | 18 WASHER (17.5X30X3.5-MM THK) | 3 |
