System And Components
383-1834 LINES GP-AIR -ATAACS/N RTL1-UP
Group No: 383-1834
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2177088 | 1 HOSE | 2 | |
| 2556264 | 2 GASKET | 1 | |
| 3002396 | 3 TUBE AS | 1 | |
| 3668500 | 4 HOSE | 2 | |
| 4225165 | 5 PLATE AS | 2 | |
| 4225168 | 6 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4225170 | 7 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4380850 | 8 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4502342 | 9 BRACKET AS | 1 | |
| 4502345 | 10 BRACKET AS | 1 | |
| 4662368 | 11 TUBE | 1 | |
| 4662369 | 12 TUBE | 1 | |
| 4662371 | 13 TUBE AS | 2 | |
| 1565745 | 14 CLAMP-HALF | 16 | |
| 1984777 | 15 WASHER-HARD (11X25X10-MM THK) | 40 | |
| 2087448 | 16 CLAMP | 8 | |
| 2338350 | 17 CLAMP (T-BOLT) | 8 | |
| 3445674 | 18 NUT (M8X1.25-THD) | 8 | |
| 3445675 | 19 NUT (M10X1.5-THD) | 8 | |
| 4W3753 | 20 SPACER (13.5X25X38.1-MM THK) | 4 | |
| 7X2537 | 21 BOLT (M8X1.25X35-MM) | 8 | |
| 8T4185 | 22 BOLT (M10X1.5X50-MM) | 12 | |
| 8T4196 | 23 BOLT (M10X1.5X35-MM) | 8 | |
| 8T4224 | 24 WASHER-HARD (8.8X16X2-MM THK) | 16 | |
| 8T5005 | 25 BOLT (M10X1.5X70-MM) | 4 | |
| 8T4195 | 26 BOLT (M10X1.5X30-MM) | 8 |
