System And Components
457-5180 LINES GP-AIR -UPPERS/N WHD1-UP
Group No: 457-5180
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P4869 | 1 CLAMP-HOSE | 4 | |
| 7N6986 | 2 SUPPORT | 4 | |
| 5P3860 | 3 CLAMP-HOSE (T-BOLT) | 4 | |
| 2086135 | 4 CLIP (SLOT) | 4 | |
| 2086136 | 5 CLIP (TAB) | 4 | |
| 2094466 | 6 HOSE | 4 | |
| 2684743 | 7 HOSE | 4 | |
| 2722400 | 8 ELBOW | 2 | |
| 2723196 | 9 TUBE | 2 | |
| 2723475 | 10 BRACKET | 2 | |
| 3215895 | 11 SHIELD AS | 4 | |
| 3603692 | 12 PLUG (9/16-18-THD)(EXTERNAL) | 2 | |
| 4529342 | 13 CLAMP AS | 4 | |
| 4650534 | 14 TUBE AS | 1 | |
| 4650535 | 15 TUBE AS | 1 | |
| 4749935 | 16 ADAPTER | 2 | |
| 4749937 | 17 BRACKET | 4 | |
| 0S1588 | 18 BOLT (3/8-16X1.25-IN) | 14 | |
| 1653929 | 19 BOLT (3/8-16X1.5-IN) | 4 | |
| 0T0055 | 20 BOLT (3/8-16X4.25-IN) | 8 | |
| 2147568 | 21 SEAL-O-RING | 2 | |
| 2162211 | 22 CLAMP (T-BOLT) | 16 | |
| 2385080 | 23 SEAL-O-RING | 1 | |
| 2K4973 | 24 LOCKNUT (3/8-16-THD) | 8 | |
| 6V1943 | 25 BOLT-HIGH TEMPERATURE (3/8-16X1.125-IN) | 8 | |
| 8M9124 | 26 WASHER (10X22.5X8-MM THK) | 8 | |
| 5M2894 | 27 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 6V3917 | 29 SEAL-O-RING | 8 | |
| 9S4185 | 30 PLUG (3/4-16-THD) | 1 | |
| 9S8752 | 31 NUT-FULL (3/8-16-THD) | 10 | |
| 9X6458 | 32 WASHER-HARD (10.2X22.5X3-MM THK) | 20 |
