System And Components
382-8053 FRAME GPS/N RTL1-109
Group No: 382-8053
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4D5768 | 1 BOLT (7/8-9X13.25-IN) | 1 | |
| 5T0504 | 2 WASHER (24X150X20-MM THK) | 2 | |
| 5T1351 | 3 BRACKET | 2 | |
| 5T1353 | 4 SPACER (17X32X49-MM THK) | 4 | |
| 5T4897 | 5 SPACER (40.9X48.3X45-MM THK) | 4 | |
| 5T5947 | 6 PIN | 1 | |
| 7I5494 | 7 BEARING | 4 | |
| 2493771 | 8 ROD | 2 | |
| 3168771 | 9 PLATE | 2 | |
| 3828054 | 10 FRAME AS | 1 | |
| 3943521 | 11 TUBE AS | 1 | |
| 3988247 | 12 PLATE | 1 | |
| 4157983 | 13 PLATE | 8 | |
| 4187328 | 14 STEP AS | 1 | |
| 4193249 | 15 PLUG AS | 12 | |
| 4J0519 | SEAL-O-RING | 1 | |
| 4920629 | 16 PLATE | 1 | |
| 1984781 | 17 WASHER-HARD (22X40X10-MM THK) | 16 | |
| 2J3505 | 18 NUT-FULL (7/8-9-THD) | 1 | |
| 3E9411 | 19 WASHER-HARD (17.5X38X6-MM THK) | 8 | |
| 4K0367 | 20 NUT-FULL (5/8-11-THD) | 8 | |
| 5P8249 | 21 WASHER-HARD (24X41.5X4-MM THK) | 1 | |
| 7X2563 | 22 BOLT (M20X2.5X60-MM) | 8 | |
| 7Y5232 | 23 BOLT (M30X3.5X70-MM) | 8 | |
| 8P6640 | 24 WASHER-HARD (17X54X3-MM THK) | 4 | |
| 8T4121 | 25 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4123 | 26 WASHER (22X35X3.5-MM THK) | 8 | |
| 8T4131 | 27 NUT (M20X2.5-THD) | 8 | |
| 8T4132 | 28 NUT (M16X2-THD) | 4 | |
| 8T4136 | 29 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4175 | 30 BOLT (M16X2X90-MM) | 4 | |
| 2135007 | 31 BOLT (M20X2.5X80-MM) | 8 | |
| 9X8257 | 32 WASHER (17.5X30X3.5-MM THK) | 4 | |
| 9X8399 | 33 WASHER (33X56X6-MM THK) | 8 |
