System And Components
424-1206 VALVE GP-AIR CONTROLS/N 4YR1-UP; 89Z1-UP
Group No: 424-1206
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3438109 | 1 ELBOW-OUTLET | 1 | |
| 3653006 | 2 VALVE GP-AIR CONTROL | 1 | |
| 3488778 | SEAL | 1 | |
| 3765546 | 3 BRACKET AS | 1 | |
| 3855773 | 4 CONNECTOR AS | 1 | |
| 5P1046 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3893708 | 5 PLUG AS | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 3983751 | 6 SENSOR GP-PRESSURE (ARD COMBUSTION AIR) | 1 | |
| 4152415 | 7 HOSE-AIR | 1 | |
| 4152416 | 8 ELBOW-AIR INLET | 1 | |
| 4241207 | 9 TUBE AS | 1 | |
| 1246275 | 10 CLAMP-HOSE | 2 | |
| 1860815 | 11 BOLT (M6X1X20-MM) | 2 | |
| 1917805 | 12 ELBOW AS | 1 | |
| 0307947 | ADAPTER-ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 8T6869 | 13 BOLT (M8X1.25X60-MM) | 4 | |
| 8T4224 | 14 WASHER-HARD (8.8X16X2-MM THK) | 10 | |
| 3441193 | 15 BOLT (M8X1.25X25-MM) | 4 | |
| 3441195 | 16 BOLT (M8X1.25X100-MM) | 2 | |
| 3441200 | 17 WASHER-HARD (6.6X12X2-MM THK) | 2 |
