System And Components
228-8646 DRIVE GP-FANS/N 7KR1-UP; 86Z1-UP
Group No: 228-8646
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2432310 | 1 COVER | 1 | |
| 2563867 | 2 ADAPTER-FAN | 1 | |
| 3485434 | 3 IDLER AS | 1 | |
| 3812511 | 4 BELT TENSIONER (FAN DRIVE) | 1 | |
| 3101945 | 5 STUD-TAPERLOCK (M12X1.75X70-MM) | 4 | |
| 3300659 | 6 BELT-SERPENTINE | 1 | |
| 5609704 | 7 DRIVE GP-FAN | 1 | |
| 8T4121 | 8 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 9 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4178 | 10 BOLT (M10X1.5X90-MM) | 1 | |
| 8T4223 | 11 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4244 | 12 NUT (M12X1.75-THD) | 4 | |
| 8T4896 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 9B7237 | 14 BOLT (3/8-16X1.25-IN) | 6 | |
| 9F4446 | 15 SEAL-O-RING | 1 |
