System And Components
121-5800 BYPASS GP-EXHAUSTS/N 7TR1-1675
Group No: 121-5800
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1364405 | 1 BYPASS GP-EXHAUST | 1 | |
| 2N9288 | 2 STUD-TAPERLOCK (3/8-16X1.67-IN) | 4 | |
| 5M2894 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 1687800 | 4 LOCKNUT (3/8-16-THD) | 4 | |
| 0321267 | 5 CONNECTOR (STRAIGHT) | 1 | |
| 4P0707 | 6 CLAMP AS | 2 | |
| 7C9710 | 7 GASKET | 1 | |
| 9G5127 | 8 BREATHER (ATMOSPHERIC)(EXHAUST BYPASS) | 1 | |
| 4H0553 | 9 FITTING (SPECIAL) | 1 | |
| 3J1907 | 10 SEAL-O-RING | 5 | |
| 9S8004 | 11 PLUG (9/16-18-THD) | 3 | |
| 0T0065 | 12 BOLT (3/8-16X3.5-IN) | 2 | |
| 3E3510 | 13 MANIFOLD | 1 | |
| 9X6772 | 15 STRAP-CABLE | 1 | |
| 2B0941 | 16 SPACER (10.5X19X19-MM THK) | 2 | |
| 4P7581 | 17 CLIP (LADDER) | 1 | |
| 8F2396 | 18 GROMMET | 1 | |
| 1094591 | 19 VALVE GP-SOLENOID (EXHAUST BYPASS) | 1 | |
| 0L1143 | 20 BOLT (3/8-16X2.5-IN) | 1 | |
| 0S0509 | 22 BOLT (3/8-16X0.75-IN) | 3 | |
| 1F7958 | 25 NUT-FULL (1/2-13-THD) | 1 | |
| 1215821 | 27 HOSE AS | 1 | |
| 0307942 | 29 ELBOW | 1 | |
| 0350519 | 30 HOSE AS | 1 | |
| 7D1649 | 31 WASHER-HARD (13.5X32X5-MM THK) | 2 | |
| 0S1587 | 32 BOLT (1/2-13X1.75-IN) | 1 | |
| 5T9355 | 33 BRACKET | 1 | |
| 2M1908 | 34 FITTING-BULKHEAD | 1 | |
| 3S8664 | 35 CLIP | 3 | |
| 2R6806 | 37 CONNECTOR | 1 | |
| 8L3282 | 38 CONNECTOR | 1 | |
| 1160118 | 40 CLIP | 1 |
