System And Components
144-4142 LINES GP-AIR -CHASSISS/N 4AR1-UP
Group No: 144-4142
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3166065 | 1 HOSE AS | 1 | |
| 6I3348 | 2 TUBE AS | 1 | |
| 7E7788 | 3 ELBOW | 3 | |
| 8X3634 | 4 BRACKET AS | 1 | |
| 9R3845 | BOSS (M12X1.75X38-MM) | 1 | |
| 8X3635 | 5 STRIP | 6 | |
| 8X4998 | 6 PLATE AS | 1 | |
| 9R3845 | BOSS (M12X1.75X38-MM) | 1 | |
| 8X7857 | 7 BRACKET AS | 1 | |
| 8X7889 | 8 PLATE | 1 | |
| 9X3993 | 9 HOSE | 2 | |
| 1444144 | 10 ELBOW AS | 1 | |
| 6V9008 | 11 ELBOW | 1 | |
| 2338485 | 12 CLAMP (BOLT SPRING) | 24 | |
| 6V7744 | 13 LOCKNUT (M10X1.5-THD) | 12 | |
| 7E7790 | 14 HOSE | 3 | |
| 7M8485 | 15 SEAL-O-RING | 1 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 20 | |
| 8T4136 | 17 BOLT (M10X1.5X25-MM) | 8 | |
| 3159833 | 18 CONNECTOR | 1 | |
| 9X6605 | 19 U-BOLT | 6 | |
| 5K9090 | 20 SEAL-O-RING | 2 |
