System And Components
9Y-8887 PIPE GP-EXHAUST -LH TURBOSS/N 4AR1-UP
Group No: 9Y-8887
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6G7038 | 1 RING-SEAL | 1 | |
| 6T5600 | 2 BOSS | 36 | |
| 7E7902 | 3 SPRING-HIGH TEMPERATURE | 8 | |
| 7E9148 | 4 ADAPTER | 1 | |
| 7E9149 | 5 PISTON | 1 | |
| 7E9151 | 6 COVER AS | 2 | |
| 7E9152 | 7 STOP | 4 | |
| 7E9153 | 8 SLEEVE AS | 1 | |
| 7E9154 | 9 SHIELD AS | 1 | |
| 7E9155 | 10 SHIELD AS | 1 | |
| 7E9156 | 11 SHIELD AS | 2 | |
| 7E9194 | 12 ADAPTER | 1 | |
| 8X3360 | 13 TUBE AS | 1 | |
| 8X3361 | 14 ELBOW | 1 | |
| 3E4352 | 15 WASHER-HARD (8.8X20.5X2.5-MM THK) | 8 | |
| 5P4116 | 16 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 6V3822 | 17 BOLT (M10X1.5X35-MM) | 4 | |
| 6V3940 | 18 BOLT (M8X1.25X25-MM) | 48 | |
| 6V5215 | 19 BOLT (M8X1.25X16-MM) | 12 | |
| 6V5217 | 20 BOLT (M8X1.25X20-MM) | 4 | |
| 6V5839 | 21 WASHER (11X21X2.5-MM THK) | 4 | |
| 6V6317 | 22 BOLT (M10X1.5X20-MM) | 2 | |
| 9M1974 | 23 WASHER-HARD (8.8X16X2-MM THK) | 60 |
