System And Components
8Q-1450 DRIVE GP-FANCUSTOM
Group No: 8Q-1450
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T2502 | 1 BOLT (3/8-16X1.125-IN) | 4 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 4N4107 | 2 PLATE | 1 | |
| 8N9299 | 3 SUPPORT-FAN | 1 | |
| 8T8919 | 4 BOLT (1/2-13X1.75-IN) | 4 | |
| 6V8188 | 5 NUT (1/2-13-THD) | 2 | |
| 5S9062 | 6 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 8T4223 | 7 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8H9789 | 8 BALL BEARING | 1 | |
| 4N6302 | 9 V-BELT SET (INCLUDES 3-BELTS) | 1 | |
| 2P1757 | 10 HUB-FAN PULLEY | 1 | |
| 0T0573 | 11 BOLT (3/8-16X2.75-IN) | 6 | |
| 1D4717 | NUT (3/8-16-THD) | 6 | |
| 9F4446 | 12 SEAL-O-RING | 1 | |
| 6N2661 | 13 ADAPTER-FAN | 1 | |
| 8S4718 | 14 BOLT (5/16-24X3-IN) | 2 | |
| 7N2900 | 15 RETAINER | 1 | |
| 3L1425 | 16 BALL BEARING | 1 | |
| 8N5305 | 17 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 8Q1451 | 18 PULLEY-FAN DRIVE | 1 | |
| 5S2106 | 19 SEAL-LIP TYPE | 1 | |
| 7X0328 | 20 BOLT (1/2-13X3.5-IN) | 2 | |
| 8N9622 | 21 BRACKET AS-FAN | 1 |
