8S6461 CYLINDER HEAD AND VALVE MECHANISM GROUP--Side View--Part 1 of 2Serial No. 65K985 to 65K1077 & 67K1083 inclusive and 67K605 to 67K728, 67K730 & 67K732 inclusive

Group No: 8S6461
Part NumberPart NameQty
3S30181 SPRING32
1P10812 VALVE (Exhaust)16
1D46223 BOLT58
7M7875WASHER58
9S67434 CHAMBER ASSEM.8
8S41905 SEAL8
1P77596 HEAD ASSEM.2
5M62147 PLUG2
9S96998 INSERT (exhaust)8
4S8902INSERT 0.13 mm(.005 in.) O.S.8
4S8903INSERT 0.26 mm(.010 in.) O.S.8
9M32059 INSERT (Intake)8
4S8898INSERT 0.13 mm(.005 in.) O.S.8
4S8899INSERT 0.26 mm(.010 in.) O.S.8
5H707110 DIRECTOR16
3B062311 PLUG16
4N366612 GUIDE16
2M647113 PLUG3
1S954014 DOWEL2
2A442915 LOCK64
2S332116 RETAINER32
2S281317 ROTOCOIL ASSEM.32
5M266718 GASKET 4.93 mm(.194 in.) thick8
1P040719 VALVE (intake)16
1S954020 DOWEL2
