System And Components
2P7800 AIR COMPRESSOR GROUP--Type 2Engine Serial No. 78P30913 to 78P32458 & 78P39230 to 78P40899 inclusive
Group No: 2P7800
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8S4583 | 1 BOLT | 8 | |
| 8S4365 | 2 FITTING | 1 | |
| 1S7107 | GASKET | 1 | |
| 8S4581 | 3 HEAD ASSEM. | 1 | |
| 8S7599 | 4 SEAT | 2 | |
| 1A2850 | 5 STUD | 2 | |
| 1B4202 | NUT | 2 | |
| 4L7318 | 6 LOCKWASHER | 8 | |
| 9M0397 | 7 FITTING | 1 | |
| 9M0385 | PLATE | 1 | |
| 6L1884 | GASKET | 2 | |
| 2B2695 | 8 BOLT | 2 | |
| 3J5390 | 9 PLUG | 2 | |
| 8S1982 | 10 GASKET | 1 | |
| 8S4582 | 11 BLOCK ASSEM. | 1 | |
| 3K5762 | 12 PLUG | 1 | |
| 9M0382 | 13 BUSHING | 2 | |
| 9M0381 | 14 SEAT | 2 | |
| 5M6213 | 15 PLUG | 2 | |
| 9F2247 | 16 PLUG | 1 | |
| 1W2804 | 17 PISTON ASSEM. | 2 | |
| 1W2803 | PLUG | 2 | |
| 1S9875 | 18 KIT (piston ring-includes 8 rings) | 1 | |
| 0L1351 | 19 BOLT | 6 | |
| 3B4506 | LOCKWASHER | 6 | |
| 1F0006 | 20 GASKET | 1 | |
| 8S1978 | 21 COVER ASSEM. | 1 | |
| 1S9867 | 22 BEARING | 1 | |
| 5M6214 | 23 PLUG | 1 | |
| 4M0061 | 24 BOLT | 4 | |
| 5M6509 | 25 SEAL | 1 | |
| 4M5281 | 26 BOLT | 6 | |
| 3B4504 | LOCKWASHER | 6 | |
| 3H5175 | 27 GASKET | 1 | |
| 2P8671 | 28 CRANKCASE | 1 | |
| 9L1518 | 29 WASHER | 2 | |
| 1S9873 | 30 ROD ASSEM. | 2 | |
| 9M5181 | 31 BOLT | 2 | |
| 2A5328 | LOCK | 2 | |
| 4N3982 | 32 BEARING | 2 | |
| 5S5268 | 33 BEARING (.010 in. undersize) | 2 | |
| 5S5269 | BEARING (.020 in. undersize) | 2 | |
| 5S5270 | BEARING (.030 in. undersize) | 2 | |
| 2P8670 | 34 CRANKSHAFT | 1 | |
| 1S9874 | KIT (Air Compressor Valve) | 1 |
