System And Components
1N4307 RADIATOR CONVERSION GROUP--TYPE 2Serial No. 26W1 To 26W480 Inclusive & 27W1 To 27W1236 Inclusive
Group No: 1N4307
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N1418 | 1 GASKET-RADIATOR INLET | 2 | |
| 7N4051 | 2 STRIP | 2 | |
| 6N4942 | 3 GASKET-TOP TANK | 1 | |
| 6N4941 | 4 GASKET-RADIATOR CORE | 2 | |
| 7N4054 | 5 STRIP | 4 | |
| 4W4986 | 6 CORE AS-RADIATOR | 1 | |
| 8N5411 | 7 DAMPER AS | 2 | |
| 7N8441 | 8 BRACKET AS | 4 | |
| 0S1594 | 9 BOLT | 24 | |
| 5M2894 | WASHER | 24 | |
| 7M7794 | 10 STUD-WELD | 24 | |
| 1D4717 | NUT | 24 | |
| 8N8710 | 11 ANGLE AS | 2 | |
| 0S1590 | 12 BOLT | 26 | |
| 7N4039 | 13 STRIP | 2 | |
| 4N1419 | 14 GASKET-OUTLET | 1 | |
| 0S1591 | 15 BOLT | 50 | |
| 8N0335 | 16 CHANNEL AS | 2 |
