System And Components
6N3787 FAN DRIVE GROUPSerial No. 24W1521, 1524 To 1543, 1548, 1549 & 24W1551-Up
Group No: 6N3787
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1D4572 | 1 BOLT | 1 | |
| 1D4719 | NUT | 1 | |
| 2M0849 | 2 WASHER | 4 | |
| 6N3764 | 3 BRACKET AS-FAN | 1 | |
| 5B5812 | 4 DOWEL | 1 | |
| 4N0955 | 5 PIN-DOWEL | 1 | |
| 1S9209 | 6 SHAFT-TIGHTENER | 1 | |
| 1P9946 | 7 SHAFT-FAN | 1 | |
| 2P1757 | 8 HUB-FAN PULLEY | 1 | |
| 0T0573 | 9 BOLT | 6 | |
| 1D4717 | NUT | 6 | |
| 5P7979 | 10 BOLT-SELF LOCKING | 2 | |
| 4W9555 | 11 ADAPTER-FAN | 1 | |
| 3L1425 | 12 BALL BEARING | 1 | |
| 9F4446 | 13 SEAL-O-RING | 1 | |
| 2P2243 | 14 SPACER | 1 | |
| 6N5337 | 15 V-BELT SET | 1 | |
| 8H9789 | 16 BALL BEARING | 1 | |
| 9L5097 | 17 HOSE AS-END 33CM(12.99 IN.) | 1 | |
| 9L5125 | 18 ELBOW | 1 | |
| 5S2106 | 19 SEAL-LIP TYPE | 1 | |
| 1A1460 | 20 BOLT | 3 | |
| 5S9062 | 21 SPACER | 1 | |
| 3B8485 | 22 FITTING-HYDRAULIC | 2 | |
| 7N1275 | 23 PULLEY-FAN | 1 | |
| 7N2900 | 24 WASHER-RETAINING | 1 |
