System And Components
3N8164 AIR SHUT-OFF GROUP--24 Volt--Type 3Part of 3N8283 Overspeed & Air Shut-Off Group shown on Page 145
Group No: 3N8164
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3N8084 | 1 DIODE AS | 1 | |
| 9B7242 | 2 SCREW-MACHINE | 1 | |
| 4B2043 | NUT | 1 | |
| 4N2882 | 3 VALVE AS | 1 | |
| 1C0569 | 4 BOLT | 2 | |
| 9S5282 | WASHER-HARD | 2 | |
| 5S1188 | 5 SEAL-O-RING | 2 | |
| 4N1320 | 6 GASKET-ADAPTER | 1 | |
| 0S1594 | 7 BOLT | 2 | |
| 5N2761 | 8 SPRING | 1 | |
| 5N5664 | 9 BRACKET AS | 1 | |
| 4F7957 | 10 BOLT | 2 | |
| 5M2894 | 11 WASHER | 4 | |
| 3N8085 | 12 DIODE AS | 1 | |
| 4N3890 | 13 SOLENOID | 1 | |
| 5N5662 | 14 LATCH | 1 | |
| 1B4330 | 15 NUT | 1 | |
| 5N3160 | 16 STUD | 1 | |
| 5N5131 | 17 BLOCK AS | 1 | |
| 5H5744 | 18 BUSHING | 1 | |
| 3N7848 | 19 SPRING | 1 | |
| 6F0612 | 20 NUT-JAM | 1 | |
| 5N1703 | 21 SPACER | 1 | |
| 5N5129 | 22 SHAFT | 1 | |
| 5H1190 | 23 SEAL-LIP TYPE | 1 | |
| 4N2883 | 24 SHAFT-SHUT-OFF | 1 | |
| 3N8163 | 25 PIPE-AIR TRANSFER | 1 | |
| 4L8337 | 26 SEAL-O-RING | 2 | |
| 5P0537 | 27 WASHER | 4 | |
| 5N4983 | 28 ADAPTER | 1 | |
| 0S1590 | 29 BOLT | 2 | |
| 5N3852 | 30 BEARING | 2 | |
| 2L3605 | 31 PIN-SPRING | 1 | |
| 5N2829 | BUSHING | 1 |
