System And Components
5N-1729 CLUTCH GPPART OF 6N-7939 POWER TAKE-OFF GP
Group No: 5N-1729
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5N3878 | 1 PLATE-HUB & BACK | 1 | |
| 3N7952 | 2 PLATE-DRIVE | 1 | |
| 5N3879 | 3 PLATE-PRESSURE | 1 | |
| 2L8262 | 4 RING-ADJUSTMENT | 1 | |
| 0S1591 | 5 BOLT (3/8-16X1.5-IN) | 2 | |
| 9F5644 | 6 LOCKWASHER | 2 | |
| 4B4725 | 7 YOKE | 1 | |
| 5L4202 | 8 HOUSING-CLUTCH | 1 | |
| 6L5151 | 9 KEY-WOODRUFF | 2 | |
| 4B4715 | 10 COLLAR AS | 1 | |
| 0L0639 | BOLT (3/8-24X2.25-IN) | 2 | |
| 2L6267 | LOCKNUT (3/8-24-THD) | 2 | |
| 4B4722 | SHIM | 2 | |
| 5N3196 | 11 SPRING | 2 | |
| 2N9363 | 12 RETAINER-BEARING | 1 | |
| 4B7255 | 13 CONE-BEARING | 2 | |
| 6Y7652 | 14 CUP-BEARING (TAPERED ROLLER) | 1 | |
| 7L0116 | 15 LOCK | 1 | |
| 4L4866 | 16 KEY-SQUARE | 1 | |
| 5N3188 | 17 PLUNGER | 1 | |
| 5N3187 | 18 SPRING | 1 | |
| 5B6159 | 19 SETSCREW-POINT | 1 | |
| 1A9136 | 20 BOLT (5/16-18X0.687-IN) | 1 | |
| 3F9556 | 21 LOCKWASHER | 1 | |
| 4B4775 | 22 HOSE AS (30.48 CM) | 1 | |
| 5N3190 | 23 PAD-SPRING MOUNTING | 1 | |
| 6L3965 | 24 PIN | 6 | |
| 6L3960 | 25 PIN-COTTER | 6 | |
| 2L8259 | 26 LEVER | 3 | |
| 6L3964 | 27 PIN-COTTER | 3 | |
| 6L3966 | 28 PIN | 3 | |
| 5N9315 | 29 RING-DRIVE (72-TEETH) | 1 | |
| 5N3191 | 30 PAD | 2 | |
| 5N3186 | 31 SPRING | 4 | |
| 5N3184 | 32 SPRING (OUTER) | 2 | |
| 5N3185 | 33 SPRING (INNER) | 2 | |
| 5N3189 | 34 SPRING | 2 | |
| 2L8257 | 35 NUT-HUB | 1 | |
| 4B4771 | 36 LOCK | 1 | |
| 1L9087 | 37 KEY | 1 | |
| 5N3192 | 38 SPRING | 2 | |
| 3N7955 | 39 SPRING | 1 | |
| 9S1354 | 40 NUT (5/8-18-THD) | 1 | |
| 6F0253 | 41 LOCKWASHER | 1 | |
| 3B8489 | 42 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 1L6931 | 43 SCREW AS-MACHINE (1/4-20X0.5-IN) | 2 | |
| 4B4787 | 44 LEVER AS | 1 | |
| 0S1587 | BOLT (1/2-13X1.75-IN) | 1 | |
| 4L2849 | 45 PLATE-PTO INFORMATION | 1 | |
| 3H3433 | 46 PIN-SPRING | 2 | |
| 8B7121 | 47 FITTING-HYDRAULIC | 2 | |
| 5D2751 | 48 WASHER-SPRING (0.406X0.687X0.125-IN THK) | 6 | |
| 5B6172 | 49 WASHER (9.7X19X0.8-MM THK) | 3 | |
| 3N7954 | 50 LOCK PIN | 1 | |
| 5N7405 | 51 SLEEVE-SLIDING | 1 | |
| 4B4756 | 52 SHAFT | 1 | |
| 5B5251 | 53 LINK | 6 | |
| 5N1780 | 54 SHAFT-CLUTCH | 1 | |
| 5N1760 | 55 WASHER-SPRING | 9 | |
| 5N1772 | KIT-CLUTCH SERVICE | 1 |
