System And Components
5N-1730 CLUTCH GPPART OF 6N-7938 POWER TAKE-OFF GP
Group No: 5N-1730
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5N3300 | 1 PLUNGER | 2 | |
| 5N3184 | 2 SPRING | 2 | |
| 5N3191 | 3 PAD | 2 | |
| 5L9645 | 4 HOUSING | 1 | |
| 3N7955 | 5 SPRING | 1 | |
| 3N7954 | 6 LOCK PIN | 1 | |
| 5N3190 | 7 PAD-SPRING MOUNTING | 1 | |
| 5N3187 | 8 SPRING | 1 | |
| 0S1591 | 9 BOLT (3/8-16X1.5-IN) | 2 | |
| 9F5644 | 10 LOCKWASHER | 2 | |
| 1K2673 | 11 YOKE | 1 | |
| 4B4756 | 12 SHAFT | 1 | |
| 2K8467 | 13 PIN-SPRING | 2 | |
| 5N3196 | 14 SPRING | 2 | |
| 6L5151 | 15 KEY-WOODRUFF | 2 | |
| 1K2811 | 16 COLLAR AS | 1 | |
| 0L0639 | BOLT (3/8-24X2.25-IN) | 2 | |
| 2F8616 | NUT-SELF LOCKING (3/8-24-THD) | 2 | |
| 2L6267 | LOCKNUT (3/8-24-THD) | 2 | |
| 5N3299 | 17 PLUNGER | 3 | |
| 5L9648 | 18 RETAINER-BEARING | 1 | |
| 5N1781 | 19 SHAFT-CLUTCH | 1 | |
| 4L4866 | 20 KEY-SQUARE | 1 | |
| 2A4576 | 21 CUP-BEARING (TAPERED ROLLER) | 2 | |
| 5L9656 | 22 CONE-BEARING (TAPERED ROLLER) | 2 | |
| 7L0116 | 23 LOCK | 1 | |
| 5N7333 | 24 SLEEVE-SLIDING | 1 | |
| 5B6159 | 25 SETSCREW-POINT | 1 | |
| 3F9556 | 26 LOCKWASHER | 1 | |
| 1A9136 | 27 BOLT (5/16-18X0.687-IN) | 1 | |
| 4B4775 | 28 HOSE AS | 1 | |
| 5B5251 | 29 LINK | 6 | |
| 6L3960 | 30 PIN-COTTER | 6 | |
| 6L3965 | 31 PIN | 6 | |
| 2L8262 | 32 RING-ADJUSTMENT | 1 | |
| 2L8259 | 33 LEVER | 3 | |
| 6L3964 | 34 PIN-COTTER | 3 | |
| 6L3966 | 35 PIN | 3 | |
| 5N3879 | 36 PLATE-PRESSURE | 1 | |
| 5N5641 | 37 PLATE-CENTER | 1 | |
| 3L8049 | 38 RING-DRIVE | 1 | |
| 3N7952 | 39 PLATE-DRIVE | 2 | |
| 5N1732 | 40 PLATE | 1 | |
| 5N3307 | 41 SPRING | 3 | |
| 1N7513 | 42 KEY-WOODRUFF | 1 | |
| 5N3185 | 43 SPRING | 2 | |
| 5L2026 | 44 LOCK | 1 | |
| 5L2017 | 45 NUT (1-3/4-16-THD) | 1 | |
| 3B8489 | 46 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 6F0253 | 47 LOCKWASHER | 1 | |
| 9S1354 | 48 NUT (5/8-18-THD) | 1 | |
| 4L2849 | 49 PLATE-PTO INFORMATION | 1 | |
| 1L6931 | 50 SCREW AS-MACHINE (1/4-20X0.5-IN) | 2 | |
| 4W2653 | 51 LEVER AS-HAND | ||
| 0S1587 | BOLT (1/2-13X1.75-IN) | 1 | |
| 8B7121 | 52 FITTING-HYDRAULIC | 2 | |
| 5B6172 | 53 WASHER (9.7X19X0.8-MM THK)(PLAIN) | 3 | |
| 5D2751 | 54 WASHER-SPRING (0.406X0.687X0.125-IN THK) | 6 | |
| 5N1760 | 55 WASHER-SPRING | 9 | |
| 5N5642 | KIT-CLUTCH SERVICE | 1 |
