System And Components
5N-7329 CLUTCH GPS/N 60M1-2372
Group No: 5N-7329
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2L8257 | 1 NUT-HUB | 1 | |
| 4B4771 | LOCK | 1 | |
| 1L9087 | 2 KEY | 1 | |
| 5N3789 | 3 CLUTCH AS | 1 | |
| 4B4805 | 4 RING | 1 | |
| 5N7059 | 5 HOUSING-CLUTCH | 1 | |
| 5N6955 | 6 PLATE | 1 | |
| 1L6931 | SCREW AS-MACHINE (1/4-20X0.5-IN) | 2 | |
| 3B8489 | 7 FITTING-GREASE (1/8-27 PTF)(CLUTCH) | 4 | |
| 9S1354 | 8 NUT (5/8-18-THD) | 1 | |
| 4K0499 | LOCKWASHER | 1 | |
| 4B4775 | 9 HOSE AS | 1 | |
| 4B4787 | 10 LEVER AS | 1 | |
| 0S1587 | BOLT (1/2-13X1.75-IN) | 1 | |
| 5N7095 | 11 PLATE-SEAL | 1 | |
| 1P4693 | 12 CUP-BEARING | 1 | |
| 6V2735 | CONE-BEARING | 1 | |
| 5N7094 | 13 SPACER (120.65X136X93.69-MM THK) | 1 | |
| 2D9454 | 14 CUP-BEARING | 1 | |
| 6V2734 | CONE-BEARING | 1 | |
| 1A2029 | 15 BOLT (3/8-16X1.125-IN) | 3 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 5N7440 | 16 PLATE-SEAL | 1 | |
| 5P5813 | 17 LOCKNUT-BEARING (2.75X18-THD) | 1 | |
| 4V7173 | LOCKNUT | 1 | |
| 6B8865 | 18 KEY-WOODRUFF | 1 | |
| 5N7441 | 19 SHAFT-CLUTCH | 1 | |
| 0127950 | 20 PLUG | 2 | |
| 4B4756 | 21 SHAFT | 1 | |
| 3B0623 | 22 PLUG-CUP (25.73-MM OD) | 2 | |
| 5N7471 | 23 WASHER (72X100X6-MM THK) | 1 | |
| 5N7153 | 24 SPACER (76X88.9X93.63-MM THK) | 1 | |
| 3B1915 | 25 BOLT (3/8-16X1.375-IN) | 6 | |
| 0S1591 | 26 BOLT (3/8-16X1.5-IN) | 2 | |
| 9F5644 | LOCKWASHER | 2 | |
| 4B4725 | 27 YOKE | 1 | |
| 6L5151 | 28 KEY-WOODRUFF | 28 |
