System And Components
1N-3270 DRIVE GP-AUXILIARYLH FRONT, 3 GROOVE PULLEY
Group No: 1N-3270
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6B6683 | 1 NUT (5/8-18-THD) | 1 | |
| 4D3704 | WASHER-HARD (17X30X5-MM THK) | 1 | |
| 2W5275 | 2 GEAR (43-TEETH) | 1 | |
| 1S1225 | 3 SEAL-O-RING | 1 | |
| 4M6107 | 4 BEARING-INNER | 1 | |
| 8T0209 | 5 RACE-ROLLER BEARING | 1 | |
| 1K6985 | 6 RING-RETAINING | 1 | |
| 1B4117 | 7 BALL BEARING | 1 | |
| 1N3231 | 8 PULLEY-AUXILIARY DRIVE (3-GROOVE) | 1 | |
| 3J0365 | 9 SEAL-LIP TYPE | 1 | |
| 2M1538 | 10 STUD-TAPERLOCK (3/8-16X1.6-IN) | 5 | |
| 9S8752 | NUT-FULL (3/8-16-THD) | 5 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 2W7917 | 11 SHAFT-AUXILIARY DRIVE | 1 | |
| 2W3262 | 12 HOUSING-AUXILIARY DRIVE | 1 | |
| 2H3777 | 13 LOCKNUT (1-5/8-18-THD) | 1 | |
| 8L9811 | 14 RING-RETAINING | 1 | |
| 5F8916 | 15 LOCKWASHER | 1 |
