System And Components
4N-8479 DRIVE GP-AUXILIARYAN ATTACHMENT
Group No: 4N-8479
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W5275 | 1 GEAR (43-TEETH) | 1 | |
| 4D3704 | 2 WASHER-HARD (17X30X5-MM THK) | 1 | |
| 2K4821 | 3 LOCKNUT (5/8-18-THD) | 1 | |
| 2W7917 | 4 SHAFT-AUXILIARY DRIVE | 1 | |
| 2H3777 | LOCKNUT (1-5/8-18-THD) | 1 | |
| 5F8916 | LOCKWASHER | 1 | |
| 1B4117 | 5 BALL BEARING | 1 | |
| 1J6474 | 6 RING-RETAINING | 1 | |
| 1K6985 | 7 RING-RETAINING | 1 | |
| 1B4076 | 8 BALL BEARING | 1 | |
| 3J0365 | 9 SEAL-LIP TYPE | 1 | |
| 2W3262 | 10 HOUSING-AUXILIARY DRIVE | 1 | |
| 4M6107 | BEARING-INNER | 1 | |
| 8T0209 | RACE-ROLLER BEARING | 1 | |
| 1S1225 | 11 SEAL-O-RING | 1 | |
| 4N8462 | 12 PULLEY-AUXILIARY DRIVE (3-GROOVE) | 1 | |
| 3D2871 | 13 STUD-TAPERLOCK (3/8-16X1.5-IN) | 5 | |
| 6V8801 | 14 NUT (3/8-16-THD) | 5 | |
| 5M2894 | 15 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 0T0573 | 16 BOLT (3/8-16X2.75-IN) | 1 | |
| 8L9811 | 17 RING-RETAINING | 1 |
