System And Components
4W-1225 CARTRIDGE GP-TURBOCHARGERPART OF 4W-1148, 4W-1226, 4W-1232, 4W-1236, 7C-2731 TURBOCHARGER GP
Group No: 4W-1225
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3411 | 1 LOCKNUT-TURBOCHARGER (7/16-20-THD) | 1 | |
| 1N3505 | 2 SPACER-THRUST | 1 | |
| 9M8919 | 3 RING-SEAL | 2 | |
| 1N3383 | 4 PLATE AS-BACKING | 1 | |
| 1N3557 | 5 RING-SEAL | 1 | |
| 4W1224 | 6 HOUSING AS-BEARING | 1 | |
| 4M6646 | PIN-GROOVED | 2 | |
| 4W1222 | 7 RING-PISTON | 1 | |
| 4W1329 | 8 SHROUD | 1 | |
| 4W1223 | 9 SHAFT AS-TURBINE | 1 | |
| 5P7234 | 10 RING-RETAINING | 3 | |
| 1N3712 | 11 BEARING-THRUST | 1 | |
| 1N3365 | 12 COLLAR-THRUST | 1 | |
| 2J3118 | 13 BOLT-LOCKING (3/8-16X1.25-IN) | 4 | |
| 1N3562 | 14 WHEEL-COMPRESSOR | 1 | |
| 1N3593 | KIT-BEARING (STANDARD)(STANDARD) | 1 | |
| 4W4832 | KIT-BEARING (0.25-MM OS) | 1 | |
| 4W4833 | KIT-BEARING (0.25-MM US) | 1 | |
| 4W4834 | KIT-BEARING (0.25-MM OS, 0.25-MM US) | 1 | |
| 7W4874 | KIT-CARTRIDGE (TURBOCHARGER) | 1 |
