System And Components
3N-9118 SHUTOFF GP-AIR24/32-VOLT
Group No: 3N-9118
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1C0569 | 1 BOLT (5/16-18X0.5-IN) | 2 | |
| 9S5282 | WASHER-HARD (8.8X14.5X2-MM THK) | 2 | |
| 4N2882 | 2 VALVE AS | 1 | |
| 3N9117 | 3 ELBOW | 1 | |
| 3N8084 | 4 DIODE AS | 1 | |
| 9B7242 | 5 SCREW-MACHINE (8-32X0.31-IN) | 1 | |
| 4B2043 | NUT (8-32-THD) | 1 | |
| 5N3852 | 6 BEARING | 4 | |
| 0S1594 | 7 BOLT (3/8-16X1-IN) | 2 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5N5664 | 8 BRACKET AS | 1 | |
| 5N5129 | 9 SHAFT | 1 | |
| 5N1703 | 10 SPACER (6.8X21X9.52-MM THK) | 1 | |
| 3N7848 | 11 SPRING | 1 | |
| 4F7957 | 12 BOLT (1/4-20X0.875-IN) | 2 | |
| 5P0537 | 13 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 3N8085 | 14 DIODE AS | 1 | |
| 4N3890 | 15 SOLENOID AS (24-VOLT) | 1 | |
| 5N5131 | 16 BLOCK AS | 1 | |
| 5H5744 | 17 BUSHING-TERMINAL | 1 | |
| 6F0612 | 18 NUT-JAM (1/4-28-THD) | 1 | |
| 5N5662 | 19 LATCH | 1 | |
| 1B4330 | 20 NUT (1/4-20-THD) | 1 | |
| 5N3160 | 21 STUD (1/4-20X2-IN) | 1 | |
| 5N2761 | 22 SPRING | 1 | |
| 5H1190 | 23 SEAL-LIP TYPE | 1 | |
| 4N2883 | 24 SHAFT-SHUTOFF | 1 | |
| 4N1320 | 25 GASKET (ADAPTER) | 1 | |
| 5S1188 | 26 SEAL-O-RING | 2 | |
| 5N2829 | 27 BUSHING-TERMINAL | 1 | |
| 2L3605 | PIN-SPRING | 1 |
