System And Components
9L6308 TURBOCHARGER GROUPEngine Serial No. 70V5101 to 70V9198 inclusive
Group No: 9L6308
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9L6239 | 1 CARTRIDGE GP-TURBOCHARGER | 1 | |
| 9L6242 | WHEEL-COMPRESSOR | 1 | |
| 3S4484 | 2 LOCKNUT-TURBOCHARGER | 1 | |
| 3S5135 | 3 SEAL-O-RING | 1 | |
| 5P5756 | 4 SEAL-O-RING | 1 | |
| 8S5169 | 5 PLATE AS-THRUST | 1 | |
| 9L6243 | 6 HOUSING AS | 1 | |
| 4M6646 | PIN-GROOVE | 2 | |
| 7N3760 | 7 SHROUD-TURBINE WHEEL | 1 | |
| 9L6244 | 8 WHEEL AS-SHAFT & TURBINE | 1 | |
| 7N3759 | 9 RING-PISTON | 1 | |
| 9N2041 | 10 KIT-BEARING | 1 | |
| 9M8915 | 11 RING-RETAINING | 3 | |
| 8S8043 | 12 SPACER-THRUST | 1 | |
| 9M8919 | 13 RING-SEAL | 2 | |
| 6N5004 | 14 BEARING-THRUST | 1 | |
| 8S8042 | 15 COLLAR-THRUST | 1 | |
| 3S4488 | 16 SCREW-MACHINE | 3 | |
| 3S4487 | 17 PLATE-LOCK | 3 | |
| 4N7158 | 18 HOUSING AS-COMPRESSOR | 1 | |
| 9L6913 | 19 HOUSING (TURBINE) | 1 | |
| 3S5126 | 20 BOLT-HIGH TEMP | 6 | |
| 3S5127 | PLATE-CLAMP | 3 | |
| 3S5128 | PLATE-LOCK | 3 | |
| 8S8097 | 21 NAMEPLATE | 1 | |
| 3S5129 | 22 CLAMP AS | 1 | |
| 4N8059 | 23 REPLACEMENT GP-BEARING (.005IN OVERSIZE OD & | 1 | |
| 4N8060 | REPLACEMENT GP-BEARING (.01IN OVERSIZE OD & | 1 | |
| 6N7239 | KIT-CARTRIDGE (INCL PARTS MARKED J) | 1 |
